Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | DS200CTBAG1ADD |
| Product Type | Terminal / Analog Termination Board |
| Series | Speedtronic Mark V (DS200 series) |
| Function | Terminal board providing analog signal termination, routing, and interfacing within the Mark V turbine control system; accepts sensor and process signals and routes them to appropriate cores/modules. |
| Application | Gas & steam turbine control and industrial automation signal management. |
| Connectors | Multiple connectors including COREBUS (JAI, JAJ), IONET, 4–20 mA input/output connectors, serial interface, and vertical pin headers. |
| Supported Signals | Analog 4–20 mA I/O, shaft voltage/current, IONET/COREBUS communication signals. |
| Power Supply | Typically powered and referenced via backplane (24 V DC supply for diagnostic circuits). |
| Ambient Operating Temp | −20 °C to +70 °C (industrial) |
| Humidity | 5 % – 95 % non‑condensing |
| Mounting | Rack‑mount printed circuit board inside Mark V control cabinet |
| Dimensions (approx.) | 160 mm × 160 mm × 120 mm (standard termination board form factor) |
| Weight | ~0.8 kg (800 g) |
| Status | Legacy GE Mark V control board; typically available as new‑surplus or refurbished. |
FAQ
FAQ
Q1. What is the DS200CTBAG1ADD used for?
It is a terminal/termination board that provides termination, routing and interfacing of analog signals and control wiring in the GE Mark V Speedtronic control system.
Q2. Which system family does this part belong to?
It is part of the GE Speedtronic Mark V (DS200 series) turbine and industrial control platform.
Q3. What types of signals does it support?
It supports analog signals including 4–20 mA inputs/outputs, IONET/COREBUS communication signals and shaft voltage/current signals.
Q4. How is DS200CTBAG1ADD mounted?
It is installed as a rack‑mount printed circuit board inside the Mark V control cabinet and connects via backplane and terminal harnesses.
Q5. What are its approximate dimensions?
The board’s approximate dimensions are 160 mm × 160 mm × 120 mm.
Q6. How much does this board weigh?
It weighs about 0.8 kg (800 g).
Q7. What environmental conditions can it operate in?
It is designed to operate in industrial environments around −20 °C to +70 °C with non‑condensing humidity.
Q8. Is the DS200CTBAG1ADD still manufactured by GE?
No — it’s a legacy Mark V series board; new production has ended, but units are available as new‑surplus or refurbished components.
