Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | DS200PTBAG1AEC |
| Product Type | Signal Termination Board |
| Series | Speedtronic Mark V (DS200 family) |
| Function | Central termination board used in turbine control systems to organize and route field wiring signals between terminal blocks and the control cabinet; facilitates connection of analog and discrete field signal cables to the control backplane. |
| Terminal Blocks | 2 × terminal blocks, each with 72 signal wire terminals |
| Connectors | 3 × 10‑pin connectors for interfacing with other system modules |
| Additional Terminals | 6 × signal wire posts for flexible field connection |
| Mounting | Rack‑mount printed circuit board inside Mark V control cabinet |
| Operating Temperature | −40 °C to +85 °C (industrial rating) |
| Humidity | 5 % – 95 % non‑condensing standard industrial tolerance |
| Dimensions | 292 mm × 76 mm × 25 mm (approx.) — 11.5 in × 3 in × 1 in |
| Weight | ~0.6 kg (1.32 lbs) |
| Environment | Designed for industrial turbine control signal termination and routing |
| Status | Legacy Mark V termination board, commonly available as surplus or refurbished part |
FAQ
FAQ
Q1. What is DS200PTBAG1AEC?
It’s a signal termination board used in GE Speedtronic Mark V turbine control systems to provide centralized field wiring connection points and route signals into the control cabinet.
Q2. What does a termination board do?
A termination board organizes and connects field signal wiring (from sensors, actuators, etc.) to the primary control backplane, simplifying installation and signal routing.
Q3. How many terminal connections does it provide?
It features two blocks with 72 signal wire terminals each, plus six additional signal wire posts for flexible connections.
Q4. What connectors are on the board?
There are three 10‑pin connectors for interfacing with other modules in the control system.
Q5. What temperature range can it operate in?
The board is rated for industrial environments from −40 °C up to +85 °C.
Q6. What are its physical size and weight?
It measures about 292 mm × 76 mm × 25 mm and weighs around 0.6 kg.
Q7. How is it mounted in a control system?
It mounts as a printed circuit board inside the Mark V control cabinet, providing a stable termination point for field wiring harnesses.
Q8. Is this board still manufactured new?
No — this is a legacy GE Mark V series termination board; new units are generally available only as surplus, refurbished, or stock on hand.
