Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | DS200SDCIG1AHB |
| Product Type | DC Power Supply & Instrumentation Board |
| Series | Speedtronic Mark V (DS200 Series) |
| Functional Description | Provides regulated DC power distribution and internal instrument feedback/signal monitoring for turbine control and DC2000 drives in industrial control systems |
| Power Input | ~125 V DC nominal |
| Output Channels | Multiple regulated DC outputs for internal board and control logic supply |
| Connectors | Multiple plug‑in board connectors; ribbon interfaces to daughter boards |
| Diagnostic Features | Status LEDs for power and operational states; voltage monitoring |
| Configuration | Jumpers and test points for setup and diagnostics |
| PCB Coating | Standard protective PCB coating |
| Mounting | Rack‑mount printed circuit board inside Mark V control cabinets |
| Operating Temperature | 0 °C to +60 °C typical industrial range |
| Storage Temperature | −40 °C to +85 °C |
| Humidity | 5 % – 95 % non‑condensing |
| Dimensions (approx.) | 85 mm × 71 mm × 30 mm (standard small Mark V power board) |
| Weight | ~0.9 kg (2.0 lbs) |
| Status | Legacy industrial turbine control board for Mark V systems |
FAQ
FAQ
Q1. What does the DS200SDCIG1AHB board do?
It supplies regulated DC power and provides internal instrumentation and signal monitoring functions in GE Speedtronic Mark V turbine control systems.
Q2. Which system series uses this board?
It belongs to the Speedtronic Mark V DS200 series used in industrial turbine and DC2000 drive control applications.
Q3. What voltage does this board operate on?
The board typically uses a nominal 125 V DC input for its power supply function.
Q4. Does the DS200SDCIG1AHB have diagnostic indicators?
Yes — it includes status LEDs and voltage monitoring circuits to aid in diagnostics.
Q5. How is this module configured?
It uses onboard jumpers and test points for configuration and setup.
Q6. What environmental conditions can it operate in?
It is designed for industrial conditions, typically 0 °C to +60 °C with standard humidity ranges.
Q7. What are the approximate dimensions of the DS200SDCIG1AHB?
The board measures about 85 mm × 71 mm × 30 mm, fitting a small Mark V control board form factor.
Q8. How much does this board weigh?
It weighs approximately 0.9 kg (2.0 lbs).
