Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | DS200TCEBG1BAA |
| Manufacturer | GE (General Electric) |
| Series | Mark V Speedtronic™ |
| Functional Acronym | TCEB |
| Product Type | Protective Core Analog I/O Board |
| Function | Processes analog and discrete signals for turbine protection and control |
| Processor | Intel 80196 Microprocessor |
| Memory | EPROM and RAM |
| Communication | IONET interface with Mark V controllers |
| Analog Inputs | Supports turbine monitoring signals |
| Analog Outputs | Control signal processing |
| Discrete I/O | Integrated digital signal handling |
| System Application | Gas and steam turbine control systems |
| Diagnostic Features | Built-in self-diagnostics and fault monitoring |
| Mounting Type | Control Rack PCB |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L × W × H) | 343 × 266 × 35 mm |
| Weight | 1.0–1.4 kg |
FAQ
FAQ
Q1: What is the main function of DS200TCEBG1BAA?
It processes analog and digital signals used in turbine protection and control applications.
Q2: Which GE platform uses this board?
The board is designed for the GE Mark V Speedtronic turbine control system.
Q3: Is DS200TCEBG1BAA an input or output board?
It performs both analog input processing and control-related output functions.
Q4: What processor does the board use?
It utilizes an Intel 80196 microprocessor for protection and control tasks.
Q5: How does it communicate with the control system?
Through the IONET communication network used in Mark V systems.
Q6: Does the board include diagnostics?
Yes, it features self-diagnostics and fault-monitoring capabilities.
Q7: What are the dimensions of DS200TCEBG1BAA?
Approximately 343 × 266 × 35 mm.
Q8: What is the weight of DS200TCEBG1BAA?
Approximately 1.0–1.4 kg.
