Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE DS3800XTFP1E1C Thyristor Fan Out Board |
| Function | Distributes gate drive signals from a single control source to multiple thyristor devices |
| System Role | Acts as a fan-out interface for parallel thyristor gate control in power electronics and turbine control applications |
| Input Interface | ONE 6-PIN male terminal |
| Output Interface | Multiple fan-out connections to thyristor gates |
| Signal Type | Pulse-width modulated (PWM) or DC gate signals |
| Isolation | Electrical separation between input control and output fan-out circuits |
| Mounting | Pre-drilled mounting points for secure chassis installation |
| PCB Construction | Industrial-grade single-layer board with protective coating |
| Operating Temperature | –30°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Rating | 5%–95% non-condensing |
| Dimensions (L × W × H) | 90 × 90 × 15 mm |
| Weight | 0.109 kg |
FAQ
FAQ
Q1: What is the primary purpose of the DS3800XTFP1E1C board?
A1: It distributes gate drive signals from a single input to multiple thyristor devices for synchronized switching.
Q2: How does this board connect to thyristor modules?
A2: It uses a single 6-pin male input terminal and multiple fan-out output pathways to the thyristor gates.
Q3: What types of signals are supported by this board?
A3: Pulse-width modulated (PWM) signals or direct DC gate signals depending on the application.
Q4: Is electrical isolation provided between input and output?
A4: Yes, the board ensures separation to prevent control signal interference and protect input circuitry.
Q5: Can this board be mounted directly in a control cabinet?
A5: Yes, it features pre-drilled mounting points for easy installation in standard chassis or cabinets.
Q6: What maintenance is typically required?
A6: Regular inspection of terminal connections and verification of fan-out signal integrity.
Q7: How does the board ensure consistent gate drive distribution?
A7: By providing equal-length signal paths and minimizing voltage drop across the fan-out channels.
Q8: Can the board be used in high-temperature environments?
A8: It is rated for operation between –30°C and +65°C, suitable for typical industrial control cabinets.
