Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS200EDCFG1BAA Exciter DC Feedback Board |
| Function | Provides DC voltage and current feedback signals for the EX2100 exciter control system |
| System Role | Converts raw exciter DC signals into conditioned feedback used for regulation and protection |
| Input Types | DC bus voltage, field voltage, field current feedback |
| Signal Conditioning | Filtering, scaling, isolation, and precision feedback conversion |
| Measurement Method | High-accuracy analog conditioning with dedicated reference paths |
| Isolation Features | Dedicated isolation stages for high-energy DC feedback circuits |
| Output Interface | Conditioned analog signals delivered to associated control modules |
| Operating Temperature | –30°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Rating | 5%–95% non-condensing |
| PCB Construction | Industrial multilayer FR-4 board with conformal protective coating |
| Mounting Method | Panel-mounted through standard EX2100 chassis slot |
| Dimensions (L × W × H) | 38 × 330 × 250 mm |
| Weight | 0.7 kg |
FAQ
FAQ
Q1: What is the primary function of the IS200EDCFG1BAA board?
A1: It provides conditioned DC voltage and current feedback signals that the exciter control system uses for regulation and monitoring.
Q2: Which feedback signals does this board typically handle?
A2: It processes DC bus voltage, field voltage, and field current feedback signals.
Q3: How does the board ensure accuracy in DC feedback measurement?
A3: Through precision scaling networks, reference-aligned circuits, and noise-filtering stages.
Q4: Is the board directly involved in exciter protection?
A4: Yes, accurate feedback from this board supports protective functions such as overcurrent and overvoltage response.
Q5: How does this board interface with other EX2100 modules?
A5: It sends conditioned analog feedback to regulator and DSP-based control modules through dedicated connectors.
Q6: What isolation methods are used for high-energy DC circuits?
A6: The board uses isolated measurement paths and separation barriers to protect control electronics.
Q7: What environmental rules must be followed during installation?
A7: Installation must comply with the rated temperature, humidity, and cabinet conditions of the EX2100 system.
Q8: Can this board be replaced while the exciter is energized?
A8: No, system power must be completely removed before installation or removal.
