Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | GE Fanuc DS200TCPSG1APE |
| Type | DC Power Input Board |
| Mounting | Panel or DIN rail |
| Connection Type | Screw terminals |
| Input Voltage | 24 V DC |
| Rated Current | 10 A |
| Operating Temperature | 0°C – +70°C |
| Storage Temperature | –20°C – +85°C |
| Vibration Resistance | 1 g |
| Dimensions | 211 × 143 × 60 mm |
| Weight | 1.18 kg |
| Protection Class | IP20 |
FAQ
FAQ
Q1: What is the purpose of the DS200TCPSG1APE DC power input board?
A1: It is used in GE Fanuc control systems to safely input external DC power to system modules.
Q2: What is the input voltage?
A2: 24 V DC.
Q3: What is the rated current?
A3: 10 A.
Q4: What is the mounting method?
A4: Can be mounted on panel or DIN rail.
Q5: What is the operating temperature range?
A5: 0°C to +70°C.
Q6: What is the protection class?
A6: IP20, suitable for control cabinet installation.
Q7: What are the dimensions and weight?
A7: Dimensions are 211 × 143 × 60 mm, weight is 1.18 kg.
Q8: Which systems is it compatible with?
A8: Mainly used for GE Fanuc PLC or DCS series control systems for DC power input and distribution modules.
