Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | GE Fanuc IC693MDL260 |
| Module Type | DC Input Module |
| Number of Input Points | 16 points |
| Input Voltage | 24 VDC, positive logic |
| Input Voltage Range | 0–30 VDC |
| Input Current | 7 mA typical @ 24 VDC |
| Response Time | 7 ms typical |
| Isolation Voltage | 1500 V RMS (channel to logic) |
| Status Indication | Individual LED per input |
| Wiring Method | Terminal block |
| Mounting | GE Fanuc Series 90-30 Rack |
| Operating Temperature | 0°C – +60°C |
| Storage Temperature | –40°C – +85°C |
| Dimensions | 130 x 40 x 110 mm |
| Weight | 0.318 kg |
FAQ
FAQ
Q1: What type of module is the IC693MDL260?
A1: It is a 24 VDC, 16-point digital input module for GE Fanuc Series 90-30 systems.
Q2: What is the supported input voltage?
A2: Standard 24 VDC, acceptable range 0–30 VDC.
Q3: What is the typical input current per point?
A3: Approximately 7 mA at 24 VDC.
Q4: Does the module provide LED indicators?
A4: Yes, each input point has its own LED status indicator.
Q5: What type of wiring connection does it use?
A5: Terminal block wiring.
Q6: Does the module have isolation protection?
A6: Yes, channel-to-logic isolation is 1500 V RMS.
Q7: What are the module’s dimensions and weight?
A7: Dimensions are 130 x 40 x 110 mm, weight approx. 0.318 kg.
Q8: Which racks are compatible with this module?
A8: It is compatible with GE Fanuc Series 90-30 PLC racks.
