Technical Specifications
| Item | Specification |
|---|---|
| Model | DS215DMCBG1AZZ03A / DS200DMCBG1AED |
| Type | Digital/Analog Mixed Control Circuit Board |
| Supported Signal Types | Digital I/O, Analog I/O, Thermocouple, LVDT/LVDR, Servo valve control |
| Digital I/O Points | Configurable according to system requirements |
| Analog Input Range | ±10 V, ±5 V, ±2 V, ±1 V, 0–5 V, 0–10 V |
| Analog Output Range | 4–20 mA / 0–10 V |
| Resolution / Accuracy | Digital signals: full logic; Analog signals: 16-bit, ±0.1% full scale |
| Signal Processing | Signal scaling, thermocouple compensation, LVDT conditioning, servo valve control |
| Interface | Multiple 34‑pin / 40‑pin connectors, jumpers, LED status indicators |
| Operating Temperature | –40 °C … +70 °C |
| Protection Rating | IP20 |
| Dimensions | 273 × 218 × 60 mm |
| Weight | 0.69 kg |
FAQ
FAQ
Q1: What signal types does this board support?
A1: Digital I/O, Analog I/O, Thermocouple, LVDT/LVDR, and servo valve control signals.
Q2: What are the analog input and output ranges?
A2: Analog input: ±10 V to 0–10 V; analog output: 4–20 mA or 0–10 V.
Q3: What is the resolution and accuracy of the board?
A3: Analog signals: 16-bit, ±0.1% full scale; Digital signals: full logic.
Q4: How does the board connect to the system?
A4: Via 34‑pin or 40‑pin connectors and jumpers for signal acquisition and output.
Q5: Does the board support servo valve control?
A5: Yes, it can directly drive and control servo valves.
Q6: What is the operating temperature range?
A6: –40 °C to +70 °C, suitable for industrial environments.
Q7: How does the board indicate status or faults?
A7: LED indicators display power, processing activity, and error conditions.
Q8: What are the typical applications?
A8: Power plants, turbine control systems, petrochemical, water treatment, and other industrial automation and process control systems.
