Technical Specifications
| Item | Specification |
|---|---|
| Model | IS230SRLYH2A / IS200SRLYH2AAA |
| Type | Digital Output DIN Rail Module |
| Main Function | Provides relay outputs for controlling external devices such as valves, contactors, alarms |
| Output Type | Form-C relay outputs |
| Number of Channels | Multiple independent relay output channels |
| Contact Rating | Suitable for 24 VDC / 48 VDC industrial loads |
| Isolation | Channel-level and system-level isolation for improved noise immunity |
| LED Indicators | Output status and fault indication |
| Wiring | DIN rail terminal wiring, easy front-access connection |
| Control Interface | Connects to GE control system backplane or extension interface |
| Power Supply | Powered from the control system internal supply |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Mounting | DIN rail mounting or panel installation |
| Dimensions | 225 x 167 x 55 mm |
| Weight | 1.14 kg |
FAQ
FAQ
Q1: What is the main function of the IS230SRLYH2A / IS200SRLYH2AAA module?
A1: It provides relay outputs to drive external switching devices such as valves, alarms, and contactors.
Q2: What type of outputs does the module provide?
A2: Form-C industrial relay outputs.
Q3: Does the module provide electrical isolation?
A3: Yes, it offers both channel and system isolation for enhanced EMI resistance.
Q4: How is the module installed?
A4: It mounts on a DIN rail or can be fixed inside a control cabinet.
Q5: What do the LED indicators show?
A5: They display channel output status and fault conditions.
Q6: What load voltage ratings are supported?
A6: It supports 24 VDC and 48 VDC industrial load control.
Q7: Does the module require an external power supply?
A7: No, it is powered by the internal system power.
Q8: What applications commonly use this module?
A8: Turbine control, alarm systems, interlock outputs, and industrial device switching.
