Technical Specifications
| Item | Specification |
|---|---|
| Model | GE Fanuc IC697ADC701 |
| Product Type | Alphanumeric Display Coprocessor |
| Series | GE Fanuc IC697 Series |
| Function | Provides processing and interface for alphanumeric operator displays |
| Display Interface | 16×2, 20×2, or 40×2 alphanumeric displays |
| Processor | 16-bit microprocessor |
| Memory | 64 KB RAM, 128 KB ROM |
| Communication Interface | RS-232/RS-422 serial interface to PLC CPU |
| Baud Rate | 1200 to 38400 bps |
| I/O Capacity | Up to 4 display units per module |
| Power Supply | 5 V DC from backplane |
| Power Consumption | 2.5 W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95%, non-condensing |
| Dimensions | 138 × 70 × 25 mm |
| Weight | 0.68 kg |
FAQ
FAQ
Q1: What is the purpose of the IC697ADC701 module?
A1: It serves as a coprocessor to manage and interface alphanumeric displays for operator control panels.
Q2: Which display types are supported?
A2: Supports 16×2, 20×2, and 40×2 alphanumeric display units.
Q3: How many displays can one module control?
A3: Up to 4 display units per module.
Q4: What is the communication interface and speed?
A4: RS-232 or RS-422 serial interface with baud rates from 1200 to 38400 bps.
Q5: What are the memory specifications?
A5: 64 KB RAM and 128 KB ROM.
Q6: How is the module powered?
A6: Powered by 5 V DC supplied from the backplane.
Q7: What are its dimensions and weight?
A7: Dimensions are 138 × 70 × 25 mm, weighing approximately 0.68 kg.
Q8: What is the operating environment for this module?
A8: Operating temperature 0°C to +60°C, storage temperature -40°C to +85°C, humidity 5%–95% non-condensing.
