Technical Specifications
| Item | Specification |
|---|---|
| Model | IS220PAICH1A |
| Product Name | Analog Input/Output Module |
| Manufacturer | GE Fanuc |
| Series | Mark VIe Control System |
| Function | Provides high-precision analog input and output interface for process signal measurement and control |
| Analog Input Channels | 8 differential inputs |
| Analog Output Channels | 8 current outputs |
| Input Signal Range | ±50 mV, ±500 mV, ±5 V, ±50 V (configurable) |
| Output Signal Range | 4–20 mA or 0–20 mA (configurable) |
| Input Impedance | >10 MΩ |
| Resolution | 16-bit A/D conversion accuracy |
| Accuracy | ±0.1% of full scale |
| Isolation Voltage | 1500 V RMS channel isolation |
| Response Time | <1 ms |
| Power Supply | 28 V DC (nominal) |
| Power Consumption | 7 W (typical) |
| Communication Interface | I/O Network Interface (IONet) |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5%–95% RH (non-condensing) |
| Cooling Method | Natural convection |
| Dimensions | 159 × 100.5 × 46 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What is the main function of the IS220PAICH1A module?
A1: It integrates analog input and output interfaces for high-precision signal acquisition and control.
Q2: How many input and output channels does it support?
A2: It provides 8 differential analog input channels and 8 current output channels.
Q3: What is the input signal range?
A3: Configurable from ±50 mV up to ±50 V.
Q4: What output types are supported?
A4: Supports 4–20 mA or 0–20 mA current outputs.
Q5: What are the accuracy and resolution of the module?
A5: Accuracy is ±0.1% of full scale with 16-bit resolution.
Q6: What is the operating temperature range?
A6: It operates within 0°C to +65°C.
Q7: How does it communicate with the control system?
A7: Via the IONet network interface.
Q8: What are the dimensions and weight of the module?
A8: Dimensions are 159 × 100.5 × 46 mm, with an approximate weight of 0.6 kg.
