Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Horner Electric / Horner APG (GE Fanuc Series 90-30 compatible) |
| Product Model | HE693PBM100 |
| Product Type | PROFIBUS DP Master Communication Module |
| Series Compatibility | GE Fanuc Series 90-30 PLC |
| Function | Provides PROFIBUS DP master communication capability for connecting distributed field devices to PLC systems |
| Communication Protocol | PROFIBUS DP only |
| PROFIBUS Mode | Master Device |
| Supported PROFIBUS Types | DP only (does not support PROFIBUS FMS or PA) |
| Maximum Slave Devices | Up to 64 PROFIBUS slave devices |
| Communication Method | Master-Slave communication |
| Connected Devices | Remote I/O modules, drives, valves, sensors, transmitters, and other PROFIBUS DP devices |
| Maximum Baud Rate | Up to 12 Mbps |
| PROFIBUS Interface | 9-pin D-sub PROFIBUS connector |
| Service Port | RS-232 serial port for configuration and firmware updates |
| Data Exchange | Cyclic I/O data exchange with PROFIBUS DP slaves |
| Special Function | Pseudo Slave function for additional PLC data access |
| Pseudo Slave Functions | SYNC/FREEZE control, additional slave diagnostics, firmware release information |
| PLC Compatibility | GE Fanuc Series 90-30 PLC |
| Required CPU | CPU351 or higher with firmware version 8.0 or later |
| Configuration Software | CIMPLICITY Control Version 2.0 or later |
| Installation Position | Any Series 90-30 local I/O slot |
| Power Consumption | Approx. 3 W @ 5 VDC |
| Power Supply | Supplied through PLC backplane |
| LED Indicators | Module status and communication diagnostics LEDs |
| Isolation | PROFIBUS network electrical isolation |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 130 × 35 × 127 mm (5.12 × 1.38 × 5.00 in.) |
| Weight | Approx. 0.27 kg (0.60 lb) |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the HE693PBM100 used for?
The HE693PBM100 is used to add PROFIBUS DP master communication capability to GE Fanuc Series 90-30 PLC systems. It allows the PLC to exchange data with remote I/O devices, drives, valves, and other PROFIBUS-compatible field equipment.
Q2: What type of PROFIBUS communication does the HE693PBM100 support?
The module supports PROFIBUS DP communication only. It does not support PROFIBUS FMS or PROFIBUS PA protocols.
Q3: How many PROFIBUS slave devices can the HE693PBM100 control?
The HE693PBM100 can operate as a PROFIBUS DP master and control communication with up to 64 slave devices when properly configured.
Q4: What devices can be connected to the HE693PBM100 network?
The module can communicate with PROFIBUS DP devices including remote I/O modules, motor drives, valves, sensors, and industrial measurement transmitters.
Q5: What PLC CPU is required for the HE693PBM100?
The module requires a GE Fanuc Series 90-30 system with a CPU351 or higher CPU and firmware version 8.0 or later for proper operation.
Q6: What communication ports are available on the HE693PBM100?
The module provides a 9-pin PROFIBUS DP communication connector for network connection and an RS-232 service port for configuration and firmware maintenance.
Q7: Does the HE693PBM100 require an external power supply?
No. The module receives operating power directly from the Series 90-30 PLC backplane. Its power consumption is approximately 3 W at 5 VDC.
Q8: What should be checked before replacing an HE693PBM100 module?
Before replacement, verify the Series 90-30 CPU compatibility, firmware version, PROFIBUS network configuration, slave device addresses, communication wiring, and PLC configuration software settings to ensure the new module operates correctly.
