Technical Specifications
| Parameter | Specification |
|---|---|
| Model | HE700GEN200 |
| Product Type | Operator Interface / HMI Panel |
| Display Type | Color TFT LCD |
| Display Size | 7-inch diagonal |
| Resolution | 800 × 480 pixels |
| Touchscreen | Resistive touch panel |
| Processor | Embedded industrial processor |
| Memory | Flash memory for application storage |
| Communication Ports | Ethernet, USB, Serial (RS-232/RS-485) |
| Power Supply | 24 V DC nominal |
| Mounting | Panel mount |
| Operating Temperature | 0 °C to +50 °C |
| Protection Rating | Front panel IP65 (installed) |
| Dimensions | Approx. 21.0 cm × 15.0 cm × 5.0 cm |
| Weight | Approx. 1.20 kg |
FAQ
FAQ
Q1: What is the HE700GEN200 used for?
It is an operator interface panel used for monitoring and controlling industrial automation systems.
Q2: What type of display does it have?
It features a 7-inch color TFT LCD touchscreen.
Q3: What communication interfaces are available?
It supports Ethernet, USB, and serial communication (RS-232/RS-485).
Q4: What power supply is required?
The unit operates on 24 V DC power.
Q5: Is the front panel protected against dust and water?
Yes, the front panel is rated IP65 when properly installed.
Q6: How is the unit mounted?
It is designed for panel mounting in control cabinets or operator stations.
Q7: What are the physical dimensions and weight?
The unit measures approximately 21.0 cm × 15.0 cm × 5.0 cm and weighs about 1.20 kg.
Q8: What is the typical operating temperature range?
It operates reliably within a temperature range of 0 °C to +50 °C.
