Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IC200CMM020-AA |
| Module Type | Modbus Master Module |
| Supported NIU Types | Genius and PROFINET Slaves |
| Max Serial Modules per NIU | Up to 2 per Genius NIU I/O station |
| RTU Slave Devices | 1 to 247 per module |
| Serial Port Type | RS-485, 15-pin D-sub, RS-232 supported via IC690ACC901 adapter |
| Baud Rates | 1200, 2400, 4800, 9600, 19200 bps; half or full duplex |
| COMMREQ Memory Requirement | 22 to 64 words depending on the content |
| RTU Master Commands | Init (65520), Diag Clear (8000), Diag Read (8001), RTU Query (8002/8003) |
| Power Consumption | Max 460 mA at 5V, 5 mA at 3.3V |
| Required Carrier | IC200CHS006 Communications Carrier |
| Dimensions (W x H x D) | 110 x 66.8 x 50 mm |
| Weight | 0.081 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What protocols does the IC200CMM020-AA module support?
A1: It supports Modbus RTU Master communication only.
Q2: Does the module support RS-232?
A2: The native port is RS-485, but RS-232 is supported via the IC690ACC901 adapter.
Q3: How many of these modules can be used per Genius NIU station?
A3: A maximum of 2 modules can be used per NIU I/O station.
Q4: How many RTU slave devices can one module communicate with?
A4: Each module can address up to 247 RTU slave devices.
Q5: Is a carrier module required for installation?
A5: Yes, the IC200CHS006 Communications Carrier is required.
Q6: What are the available baud rates for communication?
A6: Supported rates include 1200, 2400, 4800, 9600, and 19200 bps; both half and full duplex.
Q7: Which COMMREQ commands are supported?
A7: Supported commands include initialization (65520), diagnostic clear/read, and Modbus query (8002, 8003).
Q8: What are the physical dimensions and weight of the module?
A8: The module measures 110 x 66.8 x 50 mm and weighs 0.081 kg.
