Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation Solutions) |
| Product Model | IC200MDL650C |
| Product Type | Discrete Input Module |
| Series | VersaMax I/O |
| Input Type | Positive/Negative Logic Digital Input |
| Number of Input Points | 32 |
| Input Groups | 4 groups of 8 inputs |
| Nominal Input Voltage | 24 VDC |
| Input Voltage Range | 0–30 VDC |
| On-State Voltage | 15–30 VDC |
| Off-State Voltage | 0–5 VDC |
| On-State Current | 2.0–5.5 mA |
| Off-State Current | 0–0.5 mA |
| Input Impedance | 10 kΩ (max.) |
| Response Time | 0.5 ms (maximum) |
| Configurable Filter Time | 0 ms, 1.0 ms (default), or 7.0 ms |
| Isolation | 250 VAC continuous (Group-to-Group and User Input-to-Logic); 1500 VAC for 1 minute |
| Backplane Current Consumption | 50 mA @ 5 VDC |
| External Power Supply | Not Required |
| LED Indicators | One green LED per input point, one OK status LED |
| Mounting Type | VersaMax Carrier Base Mount |
| Protection | Optical Isolation |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W × H × D) | 109 × 50 × 67 mm |
| Weight | 0.25 kg |
| Application | PLC digital input acquisition for industrial automation, machine control, manufacturing systems, and process control |
| Condition | New and Original |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the GE IC200MDL650C used for?
The IC200MDL650C is used to receive 24 VDC digital signals from field devices such as pushbuttons, limit switches, proximity sensors, and relay contacts in VersaMax PLC systems.
Q2: How many input channels does the IC200MDL650C provide?
The module provides 32 digital input channels, organized into four groups of eight inputs, allowing efficient monitoring of multiple field devices.
Q3: What input voltage does the IC200MDL650C support?
It operates with a 24 VDC nominal input and accepts an input voltage range of 0–30 VDC, making it compatible with standard industrial control circuits.
Q4: What are the dimensions and weight of the IC200MDL650C?
The module measures approximately 109 × 50 × 67 mm and weighs approximately 0.25 kg.
Q5: Does the IC200MDL650C support both positive and negative logic?
Yes. Revision C (IC200MDL650C) supports both positive-logic and negative-logic input operation, providing greater flexibility for field wiring.
Q6: Does the module require an external power supply?
No. The module is powered directly from the VersaMax backplane, with a maximum backplane current consumption of 50 mA at 5 VDC.
Q7: What diagnostic features are included?
The IC200MDL650C includes one green LED for each input point to display channel status, plus an OK LED indicating that backplane power is present and the module is operating normally.
Q8: What are the advantages of the GE IC200MDL650C?
The IC200MDL650C offers high-density 32-point input capability, fast 0.5 ms response time, configurable input filtering, optical isolation, dual positive/negative logic support, low power consumption, and reliable performance for industrial automation and process control applications.
