Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation Solutions) |
| Product Model | IC200PWR102C |
| Product Type | Expanded AC Power Supply Module |
| Series | VersaMax I/O |
| Function | Provides backplane power for CPU, NIU, and I/O modules |
| Input Voltage | 120/240 VAC |
| Input Voltage Range | 85–132 VAC (120 VAC mode, jumper installed); 176–264 VAC (240 VAC mode, jumper removed) |
| Input Frequency | 47–63 Hz |
| Input Power | 27 VA |
| Output Voltage | 5 VDC and 3.3 VDC |
| Total Output Current | 1.5 A maximum |
| 3.3 VDC Output Current | Up to 1.0 A |
| 5 VDC Output Current | 1.5 A minus the 3.3 V output current used |
| Hold-up Time | 20 ms |
| Protection | Short-circuit protection and overload protection |
| Installation | Can be used as the main power supply or on a Power Supply Booster Carrier as a supplemental power supply |
| Backplane Compatibility | VersaMax CPU, NIU, and I/O stations |
| LED Indicators | Power status LED |
| Mounting Type | VersaMax Carrier Base |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W × H × D) | 49 × 133.4 × 39 mm (module only) |
| Weight | Approximately 0.22 kg |
| Application | Industrial PLC systems, machine automation, process control, and distributed I/O systems |
| Revision | Revision C |
| Condition | New and Original |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the IC200PWR102C used for?
The IC200PWR102C supplies backplane power to VersaMax CPUs, NIUs, and I/O modules. It can operate as either the main station power supply or a supplemental power supply for larger I/O configurations.
Q2: What input voltage does the IC200PWR102C support?
The module accepts 120 VAC or 240 VAC input. With the jumper installed, the input range is 85–132 VAC; with the jumper removed, the range is 176–264 VAC.
Q3: What output voltages does the module provide?
It provides regulated 5 VDC and 3.3 VDC outputs with a combined maximum output current of 1.5 A, including up to 1.0 A available on the 3.3 V output.
Q4: What are the dimensions and weight of the IC200PWR102C?
The module measures approximately 49 × 133.4 × 39 mm and weighs about 0.22 kg.
Q5: What protection features are included?
The IC200PWR102C includes short-circuit protection and overload protection to improve system reliability and safeguard connected VersaMax modules.
Q6: What is the difference between the IC200PWR102C and IC200PWR101B?
The primary difference is that the IC200PWR102C provides an expanded 3.3 VDC output (up to 1.0 A), while the IC200PWR101B provides only 0.25 A on the 3.3 V output. Both support 120/240 VAC input and a total output current of 1.5 A.
Q7: Can the IC200PWR102C be used as a supplemental power supply?
Yes. When installed on a Power Supply Booster Carrier, it can provide additional backplane power for larger VersaMax I/O systems.
Q8: What are the advantages of the GE IC200PWR102C?
The IC200PWR102C offers universal 120/240 VAC input, expanded 3.3 VDC output capability, reliable overload and short-circuit protection, compact VersaMax design, and flexible installation as either a primary or supplemental power supply for industrial automation systems.
