GE IC200PWR102D AC Power Supply Module

FAQ

Q1: What is the GE Fanuc IC200PWR102D used for?
The IC200PWR102D supplies operating power to VersaMax CPUs, NIUs, and I/O modules by converting a 120/240 VAC input into regulated 5 VDC and 3.3 VDC backplane power.

Q2: What input voltage does the IC200PWR102D require?
The module accepts 120/240 VAC nominal input, operating over 85–132 VAC or 176–264 VAC at 47–63 Hz.

Q3: What output capacity does the IC200PWR102D provide?
It provides a maximum total output current of 1.5 A, including up to 1.0 A at 3.3 VDC, with the remaining capacity available at 5 VDC.

Q4: Can the IC200PWR102D be used as a supplemental power supply?
Yes. Besides serving as the primary station power supply, it can also be installed on a Power Supply Booster Carrier (IC200PWB001) to provide additional backplane power for larger VersaMax systems.

Q5: What protection features are included in the IC200PWR102D?
The module includes short-circuit protection, overload protection, and reverse-polarity protection, helping improve system reliability and protect connected equipment.

Q6: Is the IC200PWR102D compatible with all VersaMax modules?
The power supply is compatible with VersaMax CPU modules, Network Interface Units, and standard VersaMax I/O modules, provided the total backplane current remains within the module’s output capacity.

Q7: What are the physical dimensions of the IC200PWR102D?
The module measures approximately 49 × 133.4 × 39 mm (1.93 × 5.25 × 1.54 in.), making it suitable for compact VersaMax control cabinets.

Q8: What should be checked before replacing an IC200PWR102D module?
Before replacement, verify the AC input voltage, total backplane current requirements, CPU or NIU compatibility, booster carrier installation (if used), field wiring, and system configuration to ensure reliable operation after installation.
