Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC200UDR002 |
| Product Type | Micro PLC |
| Series | VersaMax Micro |
| Function | Compact programmable logic controller with integrated digital inputs and relay outputs |
| Built-in I/O | 14 points |
| Digital Inputs | 8 × 24 VDC configurable inputs |
| Digital Outputs | 6 × Normally Open Relay Outputs |
| Input Logic | Positive or Negative Logic (configurable) |
| High-Speed Counter | Up to 4 Type A or 1 Type A + 1 Type B |
| High-Speed Counter Frequency | Up to 10 kHz |
| Power Supply | 24 VDC nominal |
| Input Voltage Range | 19.2–30 VDC (24 VDC -20% / +25%) |
| Typical Input Current | 0.16 A @ 24 VDC |
| Power Consumption | Approx. 4 W |
| Relay Output Voltage | 5–30 VDC or 5–250 VAC |
| Relay Output Current | 2 A resistive load per output |
| Relay Contact Type | Form A (SPST-NO) |
| Maximum Inrush Current | 5 A per half cycle |
| Input Current | 7.5 mA typical per input |
| Input Response Time | 0.5–20 ms configurable (100 μs in HSC mode) |
| Isolation | 1500 VAC field-to-logic, 500 VAC between groups |
| User Output Power | 24 VDC, 200 mA maximum for field devices |
| Serial Communication | RS-232 serial port with SNP/SNPX and Modbus RTU Slave support |
| Memory Protection | Built-in memory protect switch |
| Expansion Capability | Supports up to 4 expansion modules |
| Programming Software | VersaPro, Machine Edition |
| Mounting Method | DIN rail or panel mounting |
| Operating Temperature | 0°C to +55°C (32°F to +131°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 90 × 90 × 70 mm (3.54 × 3.54 × 2.76 in.) |
| Weight | Approx. 0.43 kg (0.95 lb) |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the IC200UDR002 used for?
The IC200UDR002 is a compact PLC used for machine control, process automation, material handling, packaging equipment, and other industrial control applications requiring integrated digital I/O.
Q2: How many built-in I/O points does the IC200UDR002 provide?
It includes 14 built-in I/O points, consisting of 8 digital inputs and 6 relay outputs.
Q3: What type of inputs does the IC200UDR002 support?
The controller accepts 24 VDC digital inputs that can be configured for positive logic, negative logic, or high-speed counter operation.
Q4: What devices can the relay outputs control?
The six relay outputs can switch 5–30 VDC or 5–250 VAC loads, making them suitable for motor starters, relays, solenoid valves, contactors, and indicator lamps.
Q5: Does the IC200UDR002 support expansion modules?
Yes. The controller supports up to four VersaMax Micro expansion modules, allowing additional digital or analog I/O to be added as application requirements grow.
Q6: Which communication protocols are available?
The IC200UDR002 features an RS-232 serial port supporting SNP/SNPX and Modbus RTU Slave communication protocols for integration with HMIs and supervisory systems.
Q7: Can the IC200UDR002 perform high-speed counting?
Yes. The configurable inputs can operate as high-speed counters with frequencies up to 10 kHz, making them suitable for encoder and pulse-counting applications.
Q8: What should be checked before replacing an IC200UDR002?
Before replacement, verify the 24 VDC power supply, I/O wiring, relay load ratings, communication settings, PLC program compatibility, expansion module configuration, and field device connections to ensure reliable operation after installation.
