Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC200MDD840E |
| Product Type | Discrete Mixed I/O Module |
| Series | VersaMax I/O |
| Function | Combines digital inputs and relay outputs in a single compact module |
| Input Type | 24 VDC Positive Logic Input |
| Output Type | Relay Output |
| Input Points | 20 points |
| Output Points | 12 points |
| Total I/O Points | 32 points |
| Input Voltage | 24 VDC nominal |
| Input Voltage Range | 18–30 VDC |
| Input Logic | Positive Logic |
| Input ON-State Current | 2.0–5.5 mA |
| Input OFF-State Current | 0–0.5 mA |
| Input Impedance | 10 kΩ maximum |
| Output Voltage Range | 5–265 VAC / 5–125 VDC |
| Output Contact Type | Relay Contact Output |
| Output Current Rating | 2 A maximum per point |
| Output Load Type | Resistive AC/DC loads |
| Output Isolation | No channel-to-channel isolation |
| Output Protection | No internal fuses or snubbers |
| Output Response Time | Approx. 10 ms OFF response |
| Input Response Time | Approx. 0.5 ms ON response |
| Backplane Current Consumption | 260 mA maximum @ 5 VDC |
| External Power Supply | Required for field output loads |
| LED Indicators | Individual I/O point status LEDs; OK LED indicates backplane power |
| Compatible Carrier | IC200CHS Series VersaMax carrier |
| Compatible Systems | GE Fanuc VersaMax PLC |
| Mounting Method | DIN rail mounted via VersaMax carrier |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (W × H × D) | Approx. 110 × 66.8 × 50 mm (4.3 × 2.63 × 1.96 in.) |
| Weight | Approx. 0.30 kg (0.66 lb) |
| Hardware Revision | E |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Fanuc IC200MDD840E used for?
The IC200MDD840E is used in VersaMax PLC systems to collect 24 VDC digital input signals and control external devices through relay outputs, such as solenoid valves, contactors, lamps, and control relays.
Q2: How many input and output points does the IC200MDD840E provide?
The module provides 20 digital input points and 12 relay output points, for a total of 32 discrete I/O points.
Q3: What type of input signals does the IC200MDD840E accept?
The input section accepts 24 VDC positive logic signals from field devices such as proximity switches, push buttons, limit switches, and sensors.
Q4: What type of outputs are provided by the IC200MDD840E?
The module provides 12 relay outputs capable of switching AC or DC loads, including 5–265 VAC and 5–125 VDC applications.
Q5: What is the maximum output current of the IC200MDD840E?
Each relay output can handle up to 2 A maximum load current for suitable resistive loads.
Q6: Does the IC200MDD840E require external power?
Yes. The module requires external field power for connected output loads, while the module electronics receive power from the VersaMax backplane.
Q7: Is the IC200MDD840E compatible with other VersaMax modules?
Yes. The IC200MDD840E is designed for use with GE Fanuc VersaMax systems and installs on compatible IC200CHS series carriers.
Q8: What should be checked before replacing an IC200MDD840E module?
Before replacement, verify the VersaMax carrier model, 24 VDC input wiring, relay output voltage and current requirements, field power supply capacity, terminal connections, and PLC hardware configuration.
