Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GE IC600BF832 |
| Type | Discrete Input Module |
| Function | Accepts digital input signals from field devices for logic processing |
| Number of Inputs | 32 discrete input points |
| Input Voltage Range | 24 VDC nominal |
| Logic Type | Positive logic (sourcing input) |
| Input Current (Typical) | 6 mA per point at 24 VDC |
| Isolation | 1500 V RMS channel-to-bus isolation |
| Input Filtering | Software and hardware noise suppression |
| Input Status Indication | Individual LED indicators for each input point |
| Response Time | 10 ms typical |
| Backplane Current Consumption | 200 mA typical |
| Power Supply Requirement | Supplied from base controller or rack |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN rail or panel mount |
| Compliance | CE, UL, CSA |
| Dimensions (HxWxD) | 120 x 100 x 85 mm |
| Weight | 0.363 kg |
FAQ
FAQ
Q1: What is the main function of the GE IC600BF832 Input Module?
A1: The IC600BF832 is designed to receive discrete on/off signals from field devices such as switches, relays, and sensors, and communicate their status to the control processor for automation tasks.
Q2: How many input channels does this module support?
A2: It supports 32 individual discrete input channels, enabling simultaneous monitoring of multiple field signals in industrial systems.
Q3: What is the typical operating voltage for the input channels?
A3: The module operates at a nominal 24 VDC input level, which is standard for industrial control systems and ensures reliable signal detection.
Q4: Does the IC600BF832 offer input isolation?
A4: Yes, it provides 1500 V RMS isolation between the input circuits and the backplane, protecting both the module and the controller from electrical transients.
Q5: How is signal status indicated on the module?
A5: Each input channel is equipped with an individual LED indicator that provides a visual representation of the on/off state, simplifying diagnostics and maintenance.
Q6: What type of logic does this module use?
A6: The IC600BF832 uses positive logic (sourcing input), meaning that a high input signal (typically +24 VDC) registers as an ON state.
Q7: Does the module include any noise filtering?
A7: Yes, the module incorporates both hardware and software filtering to suppress noise and prevent false triggering from electrical interference.
Q8: What kind of industrial certifications does this module meet?
A8: The IC600BF832 meets CE, UL, and CSA certifications, ensuring that it complies with international standards for safety, performance, and electromagnetic compatibility.
