Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GE IS215VPROH2B / IS215VPWRH2AC |
| Type | Emergency Turbine Protection Board |
| Function | Provides emergency overspeed and shutdown protection for turbine control systems |
| System Platform | GE Mark VI Control System |
| Input Type | Speed sensors, trip signals, and status inputs |
| Output Type | Trip relay outputs for turbine shutdown |
| Power Supply Voltage | +28 VDC nominal |
| Processor Type | Embedded industrial-grade controller |
| Communication Interface | ARCNET and system backplane |
| Protection Functions | Overspeed, critical fault detection, emergency trip activation |
| Diagnostic Features | Built-in self-test, LED status indicators, watchdog monitoring |
| Trip Solenoid Drive | Redundant output channels for trip circuits |
| Response Time | Less than 5 milliseconds |
| Isolation | Optical and galvanic isolation between circuits |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack-mounted within control cabinet |
| Compliance | CE, UL, and CSA certified |
| Dimensions (HxWxD) | 200 × 150 × 30 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the main role of the GE IS215VPROH2B / IS215VPWRH2AC board?
A1: This board serves as an emergency turbine protection module designed to detect overspeed and other critical conditions, triggering a safe and immediate turbine shutdown to prevent mechanical damage.
Q2: In which control system is this protection board typically used?
A2: It is specifically designed for integration within the GE Mark VI control system, where it operates as part of the turbine protection and safety management network.
Q3: How does the IS215VPROH2B / IS215VPWRH2AC ensure reliable protection?
A3: The board features redundant trip circuits, high-speed signal processing, and independent shutdown paths to guarantee a reliable emergency response in any fault condition.
Q4: What kind of inputs and outputs does this board handle?
A4: It accepts inputs from turbine speed sensors and trip condition signals, and provides trip relay outputs that activate shutdown solenoids to stop turbine operation safely.
Q5: What diagnostic capabilities are built into the module?
A5: The unit includes continuous self-diagnostics, LED fault indicators, and a watchdog system that monitors processor operation, ensuring any fault is detected immediately.
Q6: How fast can the protection system respond to a fault condition?
A6: The board is engineered for rapid response, with a typical reaction time of less than 5 milliseconds to detect and trigger turbine trip functions.
Q7: How does this module communicate with other system components?
A7: It communicates through ARCNET and the Mark VI backplane network, allowing seamless data transfer and coordination with control and monitoring modules.
Q8: What certifications and standards does this board comply with?
A8: The IS215VPROH2B / IS215VPWRH2AC meets CE, UL, and CSA standards, ensuring high reliability, electrical safety, and performance compliance for industrial turbine applications.
