Technical Specifications
| Parameter | Description |
|---|---|
| Model | IC660BBA100 |
| Manufacturer | GE Fanuc |
| Product Type | Genius Analog I/O Block |
| Input Range Options | -10 to +10 V, 0 to +10 V, 0 to +5 V, 4–20 mA, -5 to +5 V |
| Output Range Options | -10 to +10 V, 0 to +10 V, 4–20 mA, -5 to +5 V |
| Input Resolution | 12 bits plus sign (A/D) |
| Output Resolution | 12 bits plus sign (D/A) |
| Input Filter Time | Adjustable (typical: 128 ms) |
| Alarm Threshold Configuration | Yes, configurable high/low thresholds |
| Baud Rate | 153.6 Kbps (Standard/Extended), 76.8 Kbps, 38.4 Kbps |
| Redundancy Support | Supported (Hot Standby Mode) |
| Block Number Range | 0–31 |
| Outputs Default Mode | Hold Last State or set default after 2.5/10 seconds |
| Load Resistance | Input: External 100Ω (for 10 mA range), Output: 0–300 Ω max |
| Fuse Protection | 250V, 1/8 Amp Slow-Blow Fuse |
| Scaling Points | Fully configurable (engineering and digital units) |
| Power Supply | Internal DC-DC conversion |
| Configuration Protection | Yes (enabled/disabled) |
| Dimensions | 224.4 x 88.9 x 100 mm |
| Weight | 1.81 kg |
FAQ
FAQ
Q1: What input signal ranges are supported by IC660BBA100?
A1: Supported input ranges include -10 to +10V, 0 to +10V, 0 to +5V, 4–20mA, and -5 to +5V.
Q2: What output signal ranges are available on this module?
A2: Output ranges include -10 to +10V, 0 to +10V, 4–20mA, and -5 to +5V.
Q3: Does the IC660BBA100 support redundancy?
A3: Yes, it supports Hot Standby redundancy for high-availability systems.
Q4: What is the resolution of the analog inputs and outputs?
A4: Both inputs and outputs use a 12-bit plus sign resolution for accurate conversion.
Q5: Are alarm thresholds configurable?
A5: Yes, users can set custom high and low alarm limits per channel.
Q6: What happens to output channels when the block loses power?
A6: Outputs can be configured to hold their last state or revert to a default after 2.5 or 10 seconds.
Q7: Is there overload protection included?
A7: Yes, the block includes a built-in 250V, 1/8 Amp slow-blow fuse for protection.
Q8: Can the communication baud rate be changed?
A8: Yes, selectable baud rates include 153.6 Kbps (standard or extended), 76.8 Kbps, and 38.4 Kbps.
