Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | IC660BBA106 |
| Power Supply | 115 VAC / 125 VDC |
| Input Channels | 6 isolated 4–20mA analog inputs |
| Input Range | 4–20 mA (overrange: 0–25 mA) |
| Input Resolution | 1 µA |
| Input Accuracy @ 25°C | ±0.1% full scale |
| Input Conversion Time | 16.6–400 ms (user selectable) |
| Input Impedance | 100 Ω ±5% |
| Isolation (channel-to-channel) | 1500V RMS |
| Diagnostics | Underrange, Overrange, High/Low Alarm, Open Wire, Internal Fault |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +100°C |
| Humidity | 5–95% RH (non-condensing) |
| Heat Dissipation | 12 W max |
| Block-to-Block Isolation | 1500V for 1 minute |
| Group-to-Group Isolation | 1500V RMS |
| LEDs | Unit OK, I/O Enabled |
| Dimensions (H×W×D) | 224.4 × 88.9 × 100 mm |
| Weight | 1.8 kg |
| Mounting | Panel mount, protective enclosure required |
| Certification | Refer to GFK-0867 for standards |
FAQ
FAQ
Q1: How many input channels does the IC660BBA106 support?
A1: It supports 6 independent isolated 4–20mA analog input channels.
Q2: Does the module require user calibration?
A2: No, it does not require user calibration and is factory-set.
Q3: What is the input accuracy?
A3: Input accuracy is ±0.1% of full scale at 25°C.
Q4: What is the operating temperature range?
A4: The operating temperature range is 0°C to +60°C.
Q5: Are there any installation requirements?
A5: Yes, the module must be installed inside a protective enclosure and properly grounded.
Q6: Are the input channels isolated from each other?
A6: Yes, each input channel is isolated from the others with 1500V RMS isolation.
Q7: What are the dimensions and weight of the module?
A7: The dimensions are 224.4 × 88.9 × 100 mm and the weight is 1.8 kg.
Q8: Does the module support overrange detection?
A8: Yes, it supports overrange, underrange, open wire, and fault diagnostics.
