Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE Fanuc IC693CBL316 |
| Manufacturer | GE Fanuc / Emerson |
| Product Series | Series 90-30 PLC |
| Product Type | Serial Communication Cable |
| Function | Provides RS-232 serial communication connection between GE PLC CPUs, programming devices, and external equipment |
| Cable Type | Shielded Serial Cable |
| Cable Length | 1 meter (3 feet) |
| Connector Type | 9-pin D-sub connector to 6-pin RJ-11 connector |
| Communication Interface | RS-232 Serial Communication |
| Application | PLC programming, configuration, monitoring, firmware updates, and serial communication |
| Compatible Devices | GE Series 90-30 CPUs including IC693CPU351, IC693CPU352, IC693CPU363 and related communication ports |
| Protocol Support | GE SNP serial communication protocol |
| Shielding | Shielded cable design for improved noise resistance |
| Wire Size | 28 AWG |
| Sheath Material | PVC (Polyvinyl Chloride) |
| Operating Voltage | 5 VDC |
| Isolation Voltage | 500 VAC |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Mounting / Installation | Plug-in connection between PLC serial port and programming equipment |
| Dimensions | Approx. 1000 × 25 × 10 mm (cable length × connector area size) |
| Weight | Approx. 0.14 kg (0.31 lb) |
FAQ
FAQ
Q1: What is the GE Fanuc IC693CBL316 used for?
A: The IC693CBL316 is a serial communication cable used to connect GE Fanuc PLC CPUs with programming computers or communication interfaces for configuration, monitoring, and firmware-related operations.
Q2: Which GE PLC systems are compatible with IC693CBL316?
A: The cable is mainly designed for GE Series 90-30 PLC systems and supports compatible CPU models such as IC693CPU351, IC693CPU352, and IC693CPU363.
Q3: What connectors are included on the IC693CBL316 cable?
A: The cable has one 9-pin D-shell connector and one 6-pin RJ-11 connector, allowing connection between a PC serial port and GE PLC communication ports.
Q4: Is the IC693CBL316 a programming cable or an Ethernet cable?
A: The IC693CBL316 is a serial programming cable. It is mainly used for RS-232 communication and PLC programming rather than standard Ethernet communication.
Q5: What is the cable length and weight of IC693CBL316?
A: The cable length is approximately 1 meter (3 feet), and the weight is about 0.14 kg.
Q6: Can IC693CBL316 be used for firmware updates?
A: Yes. The cable can be used for firmware updates, configuration, and monitoring when connected to compatible GE PLC modules and programming equipment.
Q7: Does IC693CBL316 require any additional converter?
A: For equipment with a standard RS-232 serial port, no converter is normally required. If connecting to modern computers without RS-232 ports, an appropriate serial adapter may be needed.
Q8: What should be checked before using the IC693CBL316?
A: Confirm the PLC CPU model, communication port type, connector compatibility, and communication settings before connecting the cable to avoid communication errors.
