Technical Specifications
| Parameter | Description |
|---|---|
| Model | GE IC693CPU372 |
| Product Family | Series 90-30 |
| Controller Type | Embedded CPU with Ethernet capability |
| Processor | 80386EX, 32-bit |
| CPU Speed | 25 MHz |
| User Memory | 240 KB (total) |
| Internal RAM | Battery-backed |
| Programming Language | Ladder Logic |
| Communication Ports | One RS-485, One Ethernet (10Base-T) |
| Supported Protocols | SNP/SNPX, TCP/IP, SRTP, EGD |
| Power Requirements | Requires high-capacity power supply (e.g., IC693PWR330/331/332) |
| Dimensions | 130 x 33 x 119 mm |
| Weight | 0.41 kg |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Installation | Vertical rack mounting |
FAQ
FAQ
Q1: What type of processor is used in the IC693CPU372 module?
A1: The module uses an Intel 80386EX 32-bit processor operating at 25 MHz.
Q2: Does the IC693CPU372 support Ethernet communication?
A2: Yes, it features a built-in 10Base-T Ethernet port supporting TCP/IP, SRTP, and EGD protocols.
Q3: What is the total user memory available on this CPU?
A3: The IC693CPU372 provides 240 KB of total user memory.
Q4: What kind of power supply is required for the IC693CPU372?
A4: It requires a high-capacity power supply such as the IC693PWR330, PWR331, or PWR332.
Q5: Can this module be used in a redundant configuration?
A5: No, the IC693CPU372 does not support redundancy.
Q6: What programming language is used for logic development?
A6: Ladder Logic is used for programming the module.
Q7: What installation method is recommended for this CPU module?
A7: Vertical rack mounting is the standard installation method.
Q8: Is the module suitable for harsh environments?
A8: The operating temperature range is 0–60 °C, and it supports a storage range of -40 to 85 °C, making it suitable for industrial use but not extreme environments.
