Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Two-Axis Motion Control Module |
| Supported Axes | 2 independent motion control channels |
| Control Functions | Position control, velocity control, torque/force control |
| Feedback Types | Encoder feedback (quadrature), pulse train, marker input |
| Output Type | Pulse output for servo/stepper drives |
| Communication | Integrated interface for Series 90-30 PLC |
| Update Rate | High-speed scan optimized for coordinated motion |
| Position Resolution | High-precision incremental counting, module-level filtering |
| Diagnostics | Real-time status, fault flags, feedback monitoring |
| Operating Voltage | From base PLC rack backplane |
| Operating Temperature | 0°C to 60°C (typical module rating) |
| Storage Temperature | –40°C to 85°C |
| Dimensions | 100 × 38 × 80 mm |
| Weight | 0.39 kg |
FAQ
FAQ
Q1: What types of motors can the IC693DSM302 control?
A1: The module works with most servo and stepper systems that accept pulse-train command signals and provide encoder feedback.
Q2: Does the module support synchronized multi-axis motion?
A2: Yes, it supports coordinated movement between both axes for applications such as gantry systems and electronic gearing.
Q3: What encoder formats are compatible with this module?
A3: It accepts standard quadrature incremental encoders with A/B channels and an optional marker pulse.
Q4: How is motion data exchanged with the PLC CPU?
A4: Data is transferred through the Series 90-30 backplane, using registers for commands, status, and position values.
Q5: Can the module handle high-speed positioning applications?
A5: Yes, it features fast internal update cycles suitable for rapid indexing and precise point-to-point moves.
Q6: What happens if the encoder feedback is lost during operation?
A6: The module detects feedback loss and sets motion-fault status bits, allowing the PLC to take safe-state actions.
Q7: Are built-in diagnostics available for troubleshooting?
A7: The module provides extensive fault reporting such as drive error, encoder error, axis disable, and limit switch events.
Q8: Does the module support hardware limit switches?
A8: Yes, it offers dedicated inputs for positive/negative limits and home reference signals.
