Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IC693MDL660 |
| Type | DC Voltage Input Module |
| Input Points | 32 (4 groups of 8 inputs each, common referenced) |
| Input Voltage Range | 0–30 VDC |
| Logic “1” Input Voltage | 15–30 VDC |
| Logic “0” Input Voltage | 0–5 VDC |
| Input Current at 30 VDC | 7 mA typical |
| Isolation Voltage | 1500 VAC between field and logic |
| Input Impedance | 4.3 kΩ |
| Response Time | Off to On: 1 ms; On to Off: 1 ms typical |
| Backplane Current (5V) | 160 mA typical |
| LED Indicators | One per input channel (ON when logic 1 input present) |
| Dimensions (W x H x D) | 128 x 55 x 105 mm |
| Weight | 0.281 kg |
FAQ
FAQ
Q1: What is the voltage input range for IC693MDL660?
A1: The acceptable input voltage range is 0–30 VDC.
Q2: How many input points does this module have?
A2: It has 32 input points, divided into 4 groups of 8.
Q3: What is the typical input current at 30 VDC?
A3: The typical input current at 30 VDC is approximately 7 mA.
Q4: What voltage level is required to register a logic “1”?
A4: A logic “1” is registered between 15 and 30 VDC.
Q5: What is the isolation voltage of the module?
A5: The module offers 1500 VAC isolation between field and logic.
Q6: Are there status indicators for each input?
A6: Yes, each input has an LED indicator that turns ON when a logic “1” is present.
Q7: What is the response time for input changes?
A7: The typical response time is 1 millisecond for both ON and OFF transitions.
Q8: Is the module compatible with sourcing-type input devices?
A8: Yes, it is designed to work with sourcing-type input devices (positive logic).
