GE IC693MDL740F Discrete DC Output Module

FAQ

Q1: What is the GE Fanuc IC693MDL740F used for?
The IC693MDL740F is a Series 90-30 PLC digital output module used to control external DC field devices. It provides 16 transistor-based sourcing outputs for applications such as relays, contactors, solenoid valves, and indicator lights.

Q2: How many output channels does the IC693MDL740F provide?
The module provides 16 output points, divided into two groups of eight outputs. Each group shares a common connection for easier field wiring.

Q3: What voltage and current ratings are supported by the IC693MDL740F?
The module operates with 12/24 VDC field power and each output channel can handle up to 0.5 A. Each common group supports up to 2 A maximum current.

Q4: Does the IC693MDL740F require an external power supply?
Yes. The module electronics receive power from the Series 90-30 backplane, but an external DC power supply is required to provide power for connected field loads.

Q5: What type of output technology does the IC693MDL740F use?
The module uses positive logic transistor sourcing outputs, meaning it supplies current from the positive power bus to the connected load when an output is activated.

Q6: What diagnostic indicators are available on the IC693MDL740F?
The module includes individual green LED indicators that display the ON/OFF status of each output circuit, allowing operators to quickly check output operation.

Q7: What does the “F” revision indicate?
The “F” suffix identifies the hardware revision of the IC693MDL740 output module. Revision changes represent production improvements while maintaining compatibility with Series 90-30 PLC systems.

Q8: What should be checked before replacing an IC693MDL740F module?
Before replacement, verify the Series 90-30 baseplate compatibility, 12/24 VDC field power supply, output wiring, load current requirements, external protection devices, and PLC configuration settings to ensure proper operation after installation.
