GE IC693MDL760B Solenoid Valve Output Module

FAQ

Q1: What is the GE IC693MDL760B used for?
The IC693MDL760B is designed to control pneumatic solenoid valves and 24 VDC field devices in GE Series 90-30 PLC systems. It is commonly used in packaging equipment, material handling, and industrial automation applications.

Q2: How many outputs does the IC693MDL760B provide?
The module provides 11 integrated pneumatic outputs and 5 positive-logic 24 VDC transistor outputs, giving a total of 16 controllable output points.

Q3: What power supplies are required?
The module requires an external 24 VDC power supply for the solenoid valves and DC outputs, as well as a compressed air supply with a maximum pressure of 100 psi for pneumatic operation.

Q4: What are the dimensions and weight of the IC693MDL760B?
The module measures approximately 37 × 128 × 140 mm and weighs approximately 0.68 kg.

Q5: What is the current rating of the DC outputs?
Each of the 5 DC sourcing outputs can supply up to 0.5 A, with a combined maximum load current of 2.0 A for all five outputs.

Q6: Does the module provide electrical isolation?
Yes. The IC693MDL760B provides 1500 VAC isolation between the field wiring and PLC logic, along with 500 VAC isolation between output groups for improved protection and reliability.

Q7: What diagnostic features are available?
The module includes individual LED indicators for each output channel and a Power LED to indicate the presence of external solenoid power, making diagnostics and troubleshooting easier.

Q8: What are the advantages of the GE IC693MDL760B?
The IC693MDL760B combines 11 pneumatic solenoid outputs and 5 DC transistor outputs in a single module, reducing wiring complexity while providing fast response, reliable isolation, integrated pneumatic control, and seamless compatibility with the Series 90-30 PLC platform.
