Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697BEM741 |
| Product Type | FIP Bus Controller Module |
| PLC Series Compatibility | GE Fanuc Series 90-70 PLCs |
| Function | Connects PLC to FIP / WorldFIP fieldbus networks |
| Operating Voltage | 5 V DC ±5 % |
| Backplane Current | ~1.3 A @ 5 V DC |
| Data Rate | 1.0 Megabit/sec (FIP network) |
| I/O Capacity | Up to 128 field devices |
| Connectors | Dual 9-pin FIP bus + 15-pin serial interface |
| LED Indicators | 6 LEDs for status and communication |
| Configuration Software | Logicmaster 90-70 or CIMPLICITY Control 90 |
| Mounting Type | Single slot in Series 90-70 VME integrator rack |
| Operating Temperature | 0 °C to 60 °C (typical industrial) |
| Operating Humidity | 5 % to 95 % non-condensing (typical) |
| Dimensions (Approx.) | Standard Series 90-70 module form factor |
| Weight (Approx.) | ~1.8 kg (~4.0 lb) |
FAQ
FAQ
Q1: What is IC697BEM741 used for?
It is a FIP Bus controller that connects a GE Fanuc Series 90-70 PLC to FIP or WorldFIP fieldbus networks.
Q2: How many fieldbus devices can it support?
It supports up to 128 FIP field devices.
Q3: Which networks does the module support?
FIP and WorldFIP (EN50170) fieldbus networks.
Q4: What is the data transfer speed?
The FIP network operates at 1.0 Megabit per second.
Q5: What are the connectors on IC697BEM741?
It has two 9-pin FIP bus connectors and one 15-pin serial connector.
Q6: What software is used for configuration?
Configured using Logicmaster 90-70 or CIMPLICITY Control 90 software.
Q7: Does the module indicate status visually?
Yes, it includes six LED indicators for module and communication status.
Q8: What is the approximate weight of the IC697BEM741?
Approximately 1.8 kg (4.0 lb).
