Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697BEM761 |
| Product Type | I/O Interface Module |
| PLC Series Compatibility | GE Fanuc Series 90-70 PLC systems |
| Function | Interfaces IC697 I/O racks to an IC600 PLC I/O bus |
| Number of Connectors | 2 × 37-pin I/O bus connectors |
| Maximum Racks Supported | Up to 8 I/O expansion racks (16 with composite addressing) |
| I/O Points per Rack | 256 points |
| Total I/O Capacity | Up to ~2000 input + 2000 output points |
| Current Requirement | ~1.3 A from backplane |
| Communication | I/O bus to CPU exchange data for remote racks |
| Indicators | 3 LEDs: RACK, MODULE, I/O CHAIN |
| Installation Slot | Typically slot 1 of IC697 rack |
| Operating Temperature | Industrial typical (0 °C to 60 °C) |
| Operating Humidity | 5 % to 95 % non-condensing |
| Dimensions (Approx.) | Standard Series 90-70 module form factor |
| Weight (Approx.) | ~0.43 kg |
FAQ
FAQ
Q1: What is IC697BEM761 used for?
It serves as an interface module connecting I/O racks to the PLC’s I/O bus.
Q2: Which PLC series use the IC697BEM761?
It is compatible with GE Fanuc Series 90-70 PLCs.
Q3: How many expansion racks can be supported?
Supports up to 8 racks (up to 16 with composite addressing).
Q4: How many I/O points can the system support through this module?
Up to ~2000 input and 2000 output points.
Q5: What type of connectors does it have?
Two 37-pin I/O bus connectors.
Q6: What is the current requirement of the module?
It draws approximately 1.3 A from the backplane.
Q7: What indicators are on the front panel?
Three LEDs show Rack, Module, and I/O Chain status.
Q8: Where should this module be installed in the rack?
Typically installed in slot 1 of the Series 90-70 I/O rack.
