Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697BEM763 |
| Product Type | I/O Interface Module |
| Compatible PLC Series | GE Fanuc Series 90-70 PLCs |
| Function | Interfaces external I/O racks to the PLC I/O bus |
| I/O Bus Connectors | 2 × 37-pin connectors |
| Max Expansion Racks | Up to 8 I/O racks (16 with composite addressing) |
| I/O Points per Rack | 256 points |
| Total I/O Capacity | Up to ~2000 input + 2000 output points |
| Backplane Current Requirement | ~1.3 A @ 5 V DC |
| Communication | I/O data exchange via I/O bus |
| Status Indicators | LEDs for Rack, Module, I/O Chain |
| Installation Slot | Typically slot 1 in IC697 rack |
| Operating Temperature | 0 °C to 60 °C (industrial range) |
| Operating Humidity | 5 % to 95 % non-condensing |
| Dimensions (Approx.) | Standard Series 90-70 module form factor |
| Weight (Approx.) | ~0.43 kg |
FAQ
FAQ
Q1: What is IC697BEM763 used for?
It is an I/O interface module that connects external I/O racks to a Series 90-70 PLC’s I/O bus.
Q2: Which PLC family supports this module?
GE Fanuc Series 90-70 PLCs.
Q3: How many expansion I/O racks can it support?
Up to 8 racks, or 16 with composite addressing.
Q4: How many I/O points per rack are supported?
Each rack supports up to 256 I/O points.
Q5: What connectors does this module have?
Two 37-pin I/O bus connectors.
Q6: What is the typical current requirement?
Approximately 1.3 A from the backplane.
Q7: What indicators are provided on the module?
LEDs indicate Rack, Module, and I/O Chain status.
Q8: Where is IC697BEM763 installed?
It is typically installed in slot 1 of a Series 90-70 I/O rack.
