Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697CMM712 |
| Product Type | Serial Communication Module |
| Compatible PLC Series | GE Fanuc Series 90‑70 |
| Primary Function | Provides industrial serial communications between the PLC and external devices |
| Communication Interfaces | Dual serial ports (configurable RS‑232 / RS‑422 / RS‑485) (turn0search1) |
| Supported Protocols | SNP/SNP‑X (Master/Slave), CCM (Master/Slave/Peer), RTU Modbus (Slave) (turn0search1) |
| Microprocessor | 12 MHz Intel 80C186 (typical) (turn0search1) |
| Serial Ports | 2 × 25‑pin D‑sub connectors (DB25), configurable physical standards (turn0search1) |
| Baud Rate | Up to ~19.2 kbps per port (turn0search1) |
| LED Indicators | Module OK, PORT1, PORT2 (turn0search1) |
| Slot Width | Single slot in Series 90‑70 backplane (turn0search1) |
| Operating Temperature | 0 °C to ~60 °C (industrial typical) |
| Operating Humidity | 5 % to 95 % non‑condensing |
| Power Requirement | +5 V DC from backplane |
| Dimensions (Approx.) | Standard Series 90‑70 slot size (module form factor) |
| Weight (Approx.) | ~0.5 kg |
FAQ
FAQ
Q1: What is IC697CMM712 used for?
It is a serial communication module that enables PLCs to communicate with external devices and networks using standard industrial protocols.
Q2: Which PLC family supports this module?
It is compatible with GE Fanuc Series 90‑70 PLC systems.
Q3: How many serial ports does IC697CMM712 have?
It has two serial ports with configurable physical interfaces.
Q4: What communication standards are supported?
It supports RS‑232, RS‑422, and RS‑485 interfaces selectable via configuration.
Q5: What protocols can be used on this module?
It supports SNP/SNP‑X (master/slave), CCM (master/slave/peer), and RTU Modbus (slave) protocols.
Q6: What is the maximum baud rate per port?
Each port can communicate up to about 19.2 kbps.
Q7: How is module status shown?
Status is indicated by three LEDs: Module OK, PORT1, and PORT2.
Q8: Where does this module install?
It installs into a single slot of a Series 90‑70 PLC rack backplane.
