Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GE‑Emerson IC697CMM742 |
| Product Type | Ethernet Communication Interface Module |
| Compatible PLC Series | GE Fanuc Series 90‑70 PLCs |
| Primary Function | Provides Ethernet and legacy serial connectivity for 90‑70 PLC systems |
| Network Ports | 10Base‑T (RJ‑45), 10Base‑2 (BNC), AUI (15‑pin D‑connector) |
| Serial Ports | RS‑232 (6‑pin RJ‑11) & RS‑485 (15‑pin D‑connector) |
| Supported Protocols | Ethernet Global Data (EGD), SRTP, TCP/IP, plus legacy station manager over serial |
| Operating Voltage | +5 V DC and +12 V DC from PLC power supply |
| Current Draw | ~2.0 A @ +5 V DC, ~0.5 A @ +12 V DC (max with transceiver) |
| LED Indicators | MODULE OK, LAN ONLINE, SERIAL ACTIVE, STATUS |
| Installation | Single slot in Series 90‑70 PLC rack |
| Operating Temperature | 0 °C to +55 °C (32 °F to 131 °F) |
| Dimensions (Approx.) | ~94 mm × 107 mm × 89 mm (module housing) |
| Weight (Approx.) | ~0.54 kg (1.19 lb) |
FAQ
FAQ
Q1: What is the purpose of this module?
It provides Ethernet network connectivity (10Base‑T, 10Base‑2, AUI) to a GE Fanuc Series 90‑70 PLC and includes legacy serial ports for configuration and diagnostics.
Q2: Which PLC systems support IC697CMM742?
It is compatible with GE Fanuc Series 90‑70 PLC racks and CPUs.
Q3: What network interfaces are available on this module?
It includes 10Base‑T (RJ‑45), 10Base‑2 (BNC), and an AUI network port.
Q4: Does the module support serial connections?
Yes, it has an RS‑232 port (for station manager/debug) and an RS‑485 port (for software load/communication).
Q5: What protocols can this module handle?
It supports Ethernet Global Data (EGD), SRTP, TCP/IP, and serial station manager protocols.
Q6: What are the power requirements?
It operates from +5 V DC and +12 V DC supplied from the PLC power supply.
Q7: How are operational statuses indicated?
Status is shown via four LEDs: MODULE OK, LAN ONLINE, SERIAL ACTIVE, and STATUS.
Q8: What are its approximate size and weight?
About 94 mm × 107 mm × 89 mm and ~0.54 kg (1.19 lb).
