Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC697CPM915 |
| Product Type | Floating-Point Central Processing Unit (CPU) for GE Fanuc Series 90-70 PLCs |
| Processor | 32 MHz, 32-bit (floating point) |
| Memory | 1 MB battery-backed memory |
| I/O Capacity | Supports up to 12 K mixed discrete and up to 8 K analog I/O |
| Communication Ports | RS-422/RS-485 serial port (SNP/PLC programming) |
| Firmware Storage | Flash memory for system firmware |
| Scan Performance | ~0.4 µs per Boolean function |
| Operating Temperature Range | ~0 °C to +60 °C industrial standard |
| Battery Backup | ~6 months memory retention without power |
| LED Indicators | CPU status LEDs (typically 4) |
| Power Requirement | ~2.8 A from 5 V DC bus |
| Rack Slot | Slot 1 only (Series 90-70 rack) |
| Compatible Racks | CHS750, CHS782, CHS783, CHS790, CHS791 |
| Dimensions (Approx.) | ~17.44 in × 5.12 in × 5.59 in (~443 mm × 130 mm × 142 mm) |
| Weight (Approx.) | ~0.68 kg (~1.5 lbs) |
| Compliance | CE, UL/CUL 508 (typical industrial module) |
FAQ
FAQ
Q1: What is the IC697CPM915 used for?
It is a floating-point CPU module for GE Fanuc Series 90-70 PLC systems, handling control logic and I/O processing.
Q2: What processor does this CPU module use?
It uses a 32 MHz, 32-bit floating-point processor for real-time control tasks.
Q3: How much memory does the IC697CPM915 have?
It has 1 MB of battery-backed memory for program and data storage.
Q4: What communications does it provide?
It provides an RS-422/RS-485 serial port for PLC programming and communication.
Q5: What are its physical dimensions and weight?
Approximately 17.44 in × 5.12 in × 5.59 in and weighs about 0.68 kg.
Q6: How long does the CPU retain memory without power?
The onboard battery backup retains memory for about 6 months without power.
Q7: Which rack slot does this CPU require?
It must be installed in slot 1 of a compatible Series 90-70 rack.
Q8: Can it support both discrete and analog I/O?
Yes, it supports mixed discrete and analog I/O with up to 12 K points total.
