Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IS200DRLYH1BBB |
| Manufacturer | General Electric |
| Series | Mark VI Speedtronic IS200 |
| Product Type | Relay Output Module / Positive Logic Output Board |
| Functional Description | Provides multiple relay outputs with optical isolation for discrete field device control within turbine or industrial control systems. |
| Output Channels | 16 independently controlled relay outputs |
| Output Logic | Positive logic (sourcing) |
| Isolation | Optical isolation for each channel |
| Load Voltage | 12 VDC and 24 VDC |
| Load Current | Up to 2 A per channel (recommended) |
| Protection Features | Short‑circuit detection and fault monitoring |
| Operating Temperature | Suitable for industrial/rack environments (typical) |
| Connectors | Rack‑ready edge or terminal connectors (system backplane) |
| Dimensions (L × W × H) | Approx. 135 mm × 90 mm × 60 mm |
| Weight | Approx. 0.85 kg |
| Country of Origin | USA (typical for GE control boards) |
FAQ
FAQ
Q1. What is IS200DRLYH1BBB?
IS200DRLYH1BBB is a relay output module within the GE Mark VI Speedtronic IS200 control series used to drive discrete field devices with multiple isolated relay outputs.
Q2. How many relay outputs does it have?
It provides 16 independently controlled relay output channels.
Q3. What voltage does it support?
It supports 12 VDC and 24 VDC loads for field device control.
Q4. Does it offer isolation between channels?
Yes, each output channel is fully optically isolated to improve noise immunity and safety.
Q5. What load current can it handle?
Each channel can safely handle up to approximately 2 A of load current under typical recommended conditions.
Q6. What protection features are included?
The module includes short‑circuit detection and fault monitoring capabilities on outputs.
Q7. What are the physical dimensions?
The approximate dimensions are 135 mm × 90 mm × 60 mm.
Q8. How heavy is IS200DRLYH1BBB?
It weighs about 0.85 kg
