Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IS200DSFCG1AEB |
| Manufacturer | General Electric |
| Series | Mark VI Speedtronic IS200 |
| Product Type | Driver Shunt Feedback Board / IGBT Gate Driver |
| Functional Description | Provides driver circuitry and shunt feedback for IGBT drives; processes current and fault feedback and interfaces with bridge control boards. |
| Series Revision | Revision group AEB (multiple board revisions available) |
| Connectors / Mounting | Front stab‑on, plug and piercing connectors for IGBT and bridge interface |
| LED Indicators | 5 status LEDs (DS1–DS5) for diagnostics |
| Input Range | 0–5 VDC or –5 V to +5 VDC analog feedback & sensing range |
| Input Points | 46 differential, DC‑coupled inputs (depending on installation) |
| Input Update Rate | Approx. 10 ms (feedback update) |
| Resolution | Programmable 28‑ or 48‑bit resolution (system dependent) |
| Accuracy | < 0.15 % of full scale (0 °C–45 °C) |
| Overrange Protection | 160 VDC / 180 VAC continuous protection on inputs |
| Dimensions (L × W × H) | Approx. 160 mm × 160 mm × 30 mm |
| Weight | Approx. 0.8 kg |
| Board Coating | Standard Mark VI normal board coating |
| Country of Origin | United States (typical) |
FAQ
FAQ
Q1. What is IS200DSFCG1AEB?
IS200DSFCG1AEB is a Driver Shunt Feedback Board used in GE Mark VI Speedtronic turbine and drive systems to monitor and feedback current and to support IGBT gate drive circuits.
Q2. What does the board do?
It processes shunt feedback and drive signals for IGBT power electronics, providing precise current sensing, fault detection, and isolation.
Q3. What system series is this board part of?
This part belongs to the GE Mark VI Speedtronic IS200 control family.
Q4. How many LEDs are on the board and what are they for?
There are 5 status LEDs (labeled DS1–DS5) used for diagnostic status and fault indication.
Q5. What are the board’s approximate dimensions?
The board’s dimensions are about 160 mm × 160 mm × 30 mm, suitable for backplane mounting.
Q6. How much does IS200DSFCG1AEB weigh?
It weighs approximately 0.8 kg.
Q7. What type of protection does it have on its inputs?
Inputs are protected up to 160 VDC or 180 VAC continuous to safeguard against overrange conditions.
Q8. What should be considered before replacing it?
Verify system compatibility, proper orientation when installing, and follow original Mark VI manuals or OEM documentation for correct board alignment and connection.
