Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | GE IS200EPDMG1BAA |
| Manufacturer | General Electric (GE) |
| Product Type | Exciter Power Distribution Module |
| Series | Mark VI / EX2100 Excitation Control System |
| Functional Role | Distributes and conditions DC and AC power to excitation control, I/O, and protection boards within the EX2100 control cabinet. |
| Compatible Systems | GE EX2100 excitation control platforms in turbine/generator environments. |
| Input Voltage | 125 V DC from station battery; can accept one or two 120 V AC backup inputs. |
| Output Voltages | +62.5 V and –62.5 V to ground (diode-coupled DC distribution) with filtered and fused outputs. |
| Current Capacity | Up to ~100 A (total, varies by output configuration). |
| Protection Features | Overvoltage, short-circuit, thermal protection; onboard fuses for each output branch. |
| Indicators | Multiple LED indicators for status monitoring. |
| Mounting | Side-mounted on the Exciter Power Backplane (EPBP) within the excitation cabinet. |
| Operating Temperature | Typical industrial range (–30 °C to +65 °C). |
| Dimensions | 350 mm × 170 mm × 100 mm (approximate overall module size). |
| Weight | 0.36 kg (360 g). |
| Compliance | Engineered for industrial power-generation control environments. |
FAQ
FAQ
Q1. What does the GE IS200EPDMG1BAA do?
It is an exciter power distribution module that manages and distributes DC and AC power inputs to various excitation control and I/O boards in GE EX2100 systems.
Q2. Which control systems use this module?
This module is used in GE EX2100 excitation control systems within Mark VI turbine generator control platforms.
Q3. What power inputs does it accept?
It accepts a main 125 V DC input from station batteries and can also accept one or two 120 V AC backup inputs for redundancy.
Q4. What output voltages does the module provide?
The module provides filtered DC outputs of approximately +62.5 V and –62.5 V relative to ground to feed downstream boards.
Q5. How is the IS200EPDMG1BAA mounted?
It is mounted on the side of the Exciter Power Backplane inside the control cabinet.
Q6. What are its physical size and weight?
The module measures about 350 mm × 170 mm × 100 mm and weighs approximately 0.36 kg.
Q7. What protection features does it include?
It includes overvoltage, short-circuit, and thermal protection with individual fuses for output branches.
Q8. Is this module suitable for harsh industrial environments?
Yes, it is designed to operate within wide temperature and industrial control system requirements common in turbine and generator excitation systems.
