Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IS200STAOH2AAA |
| Manufacturer | General Electric (GE) |
| Product Type | Analog Output Module / Terminal Board |
| Series / System Compatibility | GE Mark VIe turbine control system |
| Functional Role | Provides precise analog signal outputs from the control system to field actuators and devices |
| Number of Channels | 8 isolated analog channels |
| Output Signal Types | 0–20 mA, 4–20 mA and 0–10 V DC (configurable) |
| Resolution | 16‑bit analog‑to‑digital / digital‑to‑analog conversion |
| Output Accuracy | ±0.05 % of full scale |
| Load Capability | Up to ~900 Ω for current mode |
| Power Supply | 24 V DC ±10 % logic/field input |
| Operating Temperature | Approximately –30 °C to +65 °C |
| Storage Temperature | Approximately –40 °C to +85 °C |
| Relative Humidity | 5 %–95 % non‑condensing |
| Isolation | Channel‑to‑channel galvanic isolation for noise immunity |
| Indicators | Status LED diagnostics (power/fault/channel) |
| Mounting | Standard VME/I/O rack or DIN‑rail mount (module style) |
| Dimensions | Approx. 220 mm × 140 mm × 50 mm |
| Weight | Approx. 0.56 kg |
| Protection | Industrial‑grade, designed for harsh environment |
FAQ
FAQ
Q1. What is the IS200STAOH2AAA?
It’s a GE Mark VIe analog output module that converts digital control commands into precise analog signals for field devices like valves and actuators.
Q2. How many analog outputs does this board provide?
It provides 8 independent isolated analog output channels.
Q3. What types of signal outputs can it generate?
It supports standard process signals such as 0–20 mA, 4–20 mA, and 0–10 V DC.
Q4. What is the accuracy and resolution of the outputs?
The outputs are high precision, with 16‑bit resolution and typical ±0.05 % full‑scale accuracy.
Q5. What power supply does it require?
It operates on 24 V DC ±10 % supply from the control rack or field power.
Q6. What environmental conditions can it tolerate?
It is built for industrial applications with an operating range of approximately –30 °C to +65 °C and wide humidity tolerance.
Q7. What happens if an output channel fails?
Each channel is isolated, so a fault on one output typically does not affect other channels and can be reported back to the controller.
Q8. Where is this module installed?
It is installed in the Mark VIe control cabinet rack or on DIN‑rail mounts where it interfaces with the system’s I/O backplane.
