Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | IS200TBAIS1C Analog Input/Output Terminal Board |
| Manufacturer | General Electric (GE) |
| Series / Product Line | GE Mark VIe / Mark VI Control Systems |
| Module Type | Analog Input/Output Terminal Board |
| Primary Function | Interfaces field analog signals (inputs/outputs) to the turbine control I/O processor |
| Number of Analog Inputs | Typically 10 analog inputs |
| Number of Analog Outputs | Typically 2 analog outputs |
| Supported Input Signal Types | 2‑wire, 3‑wire, 4‑wire transmitters; 5 V, 10 V; 0–20 mA |
| Supported Output Signal Types | 0–20 mA; 0–200 mA (configurable by jumper) |
| Connector Interface | 3 × DC‑37 pin connectors for I/O processor |
| Redundancy Support | Simplex and TMR (Triple Modular Redundancy) |
| Power Supply | 24 V DC system power |
| Noise Protection | Surge and high‑frequency noise suppression |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | Typical industrial range (to ~+85 °C) |
| Dimensions (approx.) | 33.02 cm × 10.16 cm × (thickness varies) |
| Weight (approx.) | ~1.5 kg |
| Mounting | Rack‑mount panel board |
| Compliance | Industrial control standards |
FAQ
FAQ
Q1. What is the IS200TBAIS1C used for?
It is an analog input/output terminal board that interfaces field analog signals with the turbine control system’s I/O processor.
Q2. Which control series is it compatible with?
It is compatible with GE Mark VI and Mark VIe turbine control platforms.
Q3. How many analog inputs and outputs does the board support?
It typically supports 10 analog inputs and 2 configurable analog outputs.
Q4. What types of analog signals can be connected?
It accepts 2‑wire, 3‑wire, 4‑wire transmitters, 5 V/10 V voltage signals, 0–20 mA current inputs, and 0–20 mA or 0–200 mA configurably on outputs.
Q5. Does the board support redundancy?
Yes, it supports simplex and TMR (Triple Modular Redundancy) configurations with signal fanning for redundant racks.
Q6. How does it connect to the I/O processor?
The board uses three DC‑37 pin connectors to interface with I/O processors; one can be used for simplex or all three for TMR.
Q7. What environmental range can it operate in?
It operates in typical industrial environments from about –30 °C to +65 °C.
Q8. What are the board’s physical dimensions?
Approximate size is 33.02 cm × 10.16 cm.
Q9. Does the board provide any noise protection?
Yes, it includes surge and high‑frequency noise suppression on inputs and outputs.
Q10. Is the IS200TBAIS1C still available?
Yes, it is available from industrial automation suppliers and surplus parts distributors.
