Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IS200TBCIH1BCE |
| Manufacturer | GE (General Electric) |
| Series | Mark VI Speedtronic™ |
| Functional Acronym | TBCI |
| Product Type | Contact Input Terminal Board |
| Function | Acquisition and routing of discrete (dry contact) input signals |
| Input Capacity | 24 Dry Contact Inputs |
| Terminal Blocks | 2 × Barrier Terminal Blocks |
| Total Terminals | 48 Terminals |
| Contact Excitation | DC Excitation Supply |
| Protection Features | Surge suppression and noise filtering (MOV protection) |
| System Compatibility | Mark VI and Mark VIe |
| Communication | Connected to VME processor boards (VCCC/VCRC) via cables |
| Redundancy Support | Simplex and TMR architectures |
| PCB Coating | Conformal Coated |
| Mounting Type | Control Panel / Terminal Board Assembly |
| Operating Temperature | 0°C to +60°C |
| Dimensions (L × W × H) | Approximately 330 × 102 × 48 mm |
| Weight | Approximately 0.54 kg |
FAQ
FAQ
Q1: What is the primary function of IS200TBCIH1BCE?
It collects and conditions 24 dry contact input signals from field devices.
Q2: Is it an input or output board?
It is a discrete input terminal board.
Q3: How many terminals are available?
The board provides 48 terminals arranged across two terminal blocks.
Q4: Does the board include surge protection?
Yes, it uses MOV-based surge suppression and noise filtering circuitry.
Q5: Can it be used in TMR systems?
Yes, it supports both Simplex and Triple Modular Redundant (TMR) architectures.
Q6: Which GE systems use this board?
It is designed for GE Mark VI and Mark VIe turbine control systems.
Q7: What are the dimensions?
Approximately 330 × 102 × 48 mm.
Q8: What is the weight?
Approximately 0.54 kg.
