Technical Specifications
| Parameter | Description |
|---|---|
| Model | GE IS200TBTCH1C Thermocouple Input Terminal Board |
| Function | Provides thermocouple input interface for temperature measurement in Mark VI/VIe systems |
| Input Channels | Multiple thermocouple channels for monitoring turbine and process temperatures |
| Supported Thermocouple Types | Type J, K, T, E, and others depending on configuration |
| Signal Conditioning | Cold junction compensation, filtering, and amplification for accurate readings |
| Isolation | Channel-to-channel and channel-to-ground isolation for noise immunity |
| Diagnostics | Monitors signal integrity, sensor wiring, and reports abnormal conditions |
| Communication | Interfaces via backplane to Mark VI/VIe temperature processing modules |
| Operating Voltage | Powered by 24 VDC from the control system |
| Mounting | Panel or rack-mounted within turbine control cabinets |
| Dimensions | 159 × 30 × 178 mm |
| Weight | 0.36 kg |
FAQ
FAQ
Q1: What is the main purpose of the IS200TBTCH1C board?
A1: It converts thermocouple signals into accurate digital measurements for the Mark VI/VIe system.
Q2: Which thermocouple types are supported?
A2: Common types such as J, K, T, and E, with configuration depending on system setup.
Q3: How does the board ensure accurate temperature readings?
A3: It uses cold junction compensation, signal amplification, and filtering to stabilize readings.
Q4: Does the board provide diagnostics?
A4: Yes, it monitors sensor integrity, wiring, and channel health, reporting issues to the controller.
Q5: Can this board operate in noisy industrial environments?
A5: Yes, its isolation and signal conditioning protect against electrical noise.
Q6: How is the board connected to the control system?
A6: It connects via the Mark VI/VIe backplane to the temperature processing modules.
Q7: Is the board suitable for critical turbine monitoring?
A7: Yes, it provides reliable thermocouple input for protection and process control.
Q8: Can the board be replaced without disconnecting field thermocouples?
A8: Removable terminal blocks allow easy replacement while maintaining field wiring connections.
