Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IS200TRLYH1BGG |
| Manufacturer | GE (General Electric) |
| Series | Mark VI Speedtronic™ |
| Functional Acronym | TRLY |
| Product Type | Relay Output Terminal Board |
| Function | Relay output interfacing and field device switching |
| Relay Channels | 12 Form-C relays |
| Relay Ratings | 24 VDC / 3 A, 125 VDC / 0.6 A, 120/240 VAC / 3 A |
| Power Distribution | 6 fused branches + 1 special unfused branch |
| Feedback | Voted Coil Drive Feedback |
| Protection | MOV (Metal Oxide Varistor) surge suppression |
| Terminal Blocks | 2 barrier terminal blocks |
| Total Terminals | 48 terminals |
| System Architecture | Simplex and TMR (Triple Modular Redundant) |
| Compatible Controllers | VCCC, VCRC, VGEN |
| Communication | Cable connection to VME I/O processors |
| Mounting Type | Panel-mounted terminal board |
| Operating Temperature | 0°C to +60°C |
| Dimensions (L × W × H) | Approximately 263 × 58 × 28 mm |
| Weight | Approximately 0.4–0.8 kg |
FAQ
FAQ
Q1: What is the primary function of IS200TRLYH1BGG?
It converts control signals from the Mark VI system into relay outputs for field devices.
Q2: How many relay outputs are available?
The board provides 12 Form-C relay outputs.
Q3: Does the board support solenoid outputs?
Yes. The first six relay channels can be configured for solenoid drive applications.
Q4: What protection features are included?
The board includes MOV surge suppression and coil-drive monitoring.
Q5: Can it be used in TMR systems?
Yes. It supports both Simplex and Triple Modular Redundant (TMR) architectures.
Q6: Which processor boards control the TRLY board?
Typically VCCC, VCRC, or VGEN controllers.
Q7: What are the dimensions of IS200TRLYH1BGG?
Approximately 263 × 58 × 28 mm.
Q8: What is the weight of IS200TRLYH1BGG?
Approximately 0.4–0.8 kg, depending on hardware revision and packaging.
