Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IS200TRTDH1CCC |
| Manufacturer | General Electric (GE) |
| Product Type | Resistance Temperature Detector (RTD) Input Terminal Board |
| Series / System Compatibility | GE Mark VI Speedtronic turbine control system |
| Functional Role | Converts analog RTD temperature sensor signals into conditioned data for turbine control logic |
| Number of Channels | 8 channels per board |
| RTD Input Support | 16 three‑wire RTDs via two terminal blocks |
| Supported RTD Types | Platinum (10 Ω, 100 Ω, 200 Ω), Copper (10 Ω), Nickel (120 Ω) |
| Voltage Span | 0.3532 V to 4.054 V input range |
| Maximum Lead Resistance | 15 Ω (two‑way cable resistance) |
| Terminal Connections | Two removable barrier‑type terminal blocks (24 screws each) |
| Cable Connectors | Three 37‑pin female cable connectors |
| Signal Conditioning | Noise suppression and hardware/software limit checking |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 %–95 % non‑condensing |
| Protection | Industrial conformal coating |
| Dimensions | Approx. 115 mm × 45 mm × 38 mm |
| Weight | Approx. 0.22 kg |
| Mounting | Rack slot installation inside control cabinet |
FAQ
FAQ
Q1. What is the IS200TRTDH1CCC used for?
It is an RTD input terminal board used to interface resistance temperature detector sensors to the GE Mark VI Speedtronic turbine control system.
Q2. How many temperature channels does this board support?
It supports 8 channels and can connect up to 16 three‑wire RTD sensors.
Q3. What types of RTDs can be used with this board?
It supports platinum, copper, and nickel RTDs of various resistance values (10 Ω, 100 Ω, 200 Ω, 120 Ω).
Q4. What voltage range do the RTD inputs use?
RTD inputs span approximately 0.3532 V to 4.054 V.
Q5. What signal protection features does the board have?
The board includes noise suppression circuitry and both hardware and software limit checking for reliable measurements.
Q6. What operating environment can it handle?
It operates in industrial environments from about –30 °C to +65 °C and 5 % to 95 % humidity.
Q7. How is this board physically connected?
It uses removable barrier terminal blocks and 37‑pin cable connectors to interface with sensors and processors.
Q8. What happens if this board fails?
Failure may lead to loss of accurate temperature data input, potentially compromising temperature monitoring and related control decisions.
