Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | IS200VTURH1BAB |
| Manufacturer | General Electric (GE) |
| Product Type | Primary Turbine Protection Board |
| Series / System Compatibility | GE Mark VI Speedtronic turbine control system |
| Functional Role | Monitors turbine speed, flame detectors, shaft voltage/current and initiates overspeed trip logic |
| Speed Inputs | 4 passive magnetic pulse rate inputs, 2 Hz–20 kHz |
| Speed Detection Accuracy | Approx. ±0.05 % of reading |
| Minimum Speed Detection | ~2 RPM low speed detection |
| Analog Voltage Inputs | ~6 voltage monitoring channels |
| Flame Detector Inputs | Up to 8 flame detector channels |
| Trip Solenoid Outputs | Controls 3 primary overspeed trip relays |
| Redundancy | Simplex and Triple Modular Redundant (TMR) configurations |
| Operating Voltage | ~125 V DC control power |
| Operating Temperature | Approx. 0 °C to +60 °C |
| Relative Humidity | 5 %–95 % non‑condensing |
| Protection | Conformal coating for industrial environments |
| Mounting | VME rack insertion inside turbine control cabinet |
| Dimensions | Approx. 28 cm × 23 cm × 7.6 cm |
| Weight | Approx. 0.56 kg – 0.9 kg |
| Indicators | LED status indicators for diagnostics |
FAQ
FAQ
Q1. What is the IS200VTURH1BAB used for?
It’s a primary turbine protection board for GE Mark VI turbine control systems that monitors speed, flame detectors, and other critical parameters, and commands emergency trip outputs on faults.
Q2. What types of inputs does this board accept?
It accepts four passive magnetic pulse rate speed inputs and multiple analog voltage channels for monitoring turbine and generator signals.
Q3. How many flame detector inputs does the board support?
It can process up to eight flame detector inputs commonly used in gas turbine safety applications.
Q4. What is the speed range it can detect?
It monitors turbine speed over a wide frequency range (~2 Hz to 20 kHz) corresponding to very low to high RPM.
Q5. What does it output to the turbine control system?
It controls three primary overspeed trip relays that interface with trip solenoids or breaker control boards.
Q6. Does it support redundant operation?
Yes, it supports both simplex and TMR redundant configurations for high‑availability systems.
Q7. What environmental conditions can it handle?
It is designed for industrial control environments with an approximate operating range of 0 °C to +60 °C and wide humidity tolerance.
Q8. How large and heavy is the board?
Dimensions are roughly 28 cm × 23 cm × 7.6 cm with a typical weight around 0.56 kg – 0.9 kg.
