Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IS420UCSBS1A |
| Product Type | Mark VIeS Safety Controller Module |
| Processor | Dual-core, 1.6 GHz AMD G-Series |
| Memory | 2 GB DDR3-1066 SDRAM with ECC |
| Storage | 128 GB Solid State Drive |
| Redundancy | Supports Simplex, Dual, and TMR configurations |
| Supported Protocols | Modbus TCP Slave (Read-only), EGD/UDH, OPC UA |
| IONet Ports | 3 (R, S, T) – For communication with I/O modules |
| Ethernet Port (ENET1) | For EGD/UDH, Modbus TCP Slave, and Black Channel Comm. |
| Programming Languages | FBD, RLD, Cause and Effect Matrix |
| Logic Execution Frame Rates | 10 ms, 40 ms, 80 ms, 160 ms |
| Input Voltage | 18–30 VDC, 28 VDC nominal |
| Power Consumption | Max 30.8 W |
| Operating Temperature | -40 to 70°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 95% non-condensing |
| Cooling Method | Convection |
| Mounting Method | Base-mounted |
| Safety Certifications | IEC 61508 (SIL2/SIL3 compliant) |
| Hazardous Location Ratings | Class 1 Div 2 / Class 2 Zone 2 / ATEX |
| G3 Compliant | Yes |
| Dimensions (H × W × D) | 32 × 8 × 25 mm |
| Weight | 0.25 kg |
FAQ
FAQ
Q1: What redundancy configurations are supported by the IS420UCSBS1A controller?
A1: The IS420UCSBS1A supports Simplex, Dual, and Triple Modular Redundancy (TMR) configurations.
Q2: Is the IS420UCSBS1A compliant with safety standards?
A2: Yes, it complies with IEC 61508 for SIL2 and SIL3 functional safety levels.
Q3: What type of processor does the controller use?
A3: It is equipped with a dual-core 1.6 GHz AMD G-Series processor.
Q4: What communication protocols are supported?
A4: The controller supports Modbus TCP Slave (read-only), EGD/UDH, and OPC UA.
Q5: Does the controller have internal storage?
A5: Yes, it includes a 128 GB solid state drive for control logic and data storage.
Q6: What are the typical application areas for this controller?
A6: It is widely used in emergency shutdown systems, burner management, fire and gas detection, and critical safety loop control.
Q7: Is non-volatile memory supported for program variables?
A7: Yes, it supports 3,067 non-volatile program variables, 338 forces, and 64 totalizers.
Q8: Can the IS420UCSBS1A operate in harsh environments?
A8: Yes, it operates in a wide temperature range (-40°C to 70°C), is G3 compliant, and certified for use in hazardous locations (Class 1 Div 2 / Zone 2).
