Technical Specifications (GE Multilin UR Series)
| Parameter | Specification |
|---|---|
| Part Number | UR-8FV |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | CT/VT Measurement Module |
| Function | Provides current and voltage transformer inputs for protection, metering, and control |
| CT Inputs | 3 × phase CT (1A / 5A), 1 × ground CT (1A / 5A) |
| VT Inputs | 1 × 4-terminal VT input (voltage measurement) |
| Measurement | RMS current, voltage, power system monitoring |
| Accuracy | Typically ±1% current, ±0.5% voltage (variant dependent) |
| Communication | Internal UR backplane (no external protocol) |
| Compatibility | GE Multilin UR-series protection relays |
| Installation | Plug-in module in UR relay chassis |
| Input Range | 1A / 5A CT secondary, 100–120 V VT secondary (typical) |
| Operating Temperature | -20°C to +60°C (typical industrial range) |
| Dimensions | ~152 × 178 × 38 mm (6″ × 7″ × 1.5″) |
| Weight | ~0.6–1.5 kg (commonly ~0.9 kg) |
FAQ
FAQ
Q1: What is UR 8FV used for?
It measures current and voltage signals for GE UR protection relays.
Q2: Is it a protection relay?
No. It is a measurement module, not a full relay.
Q3: What inputs does it support?
3-phase CTs, ground CT, and VT inputs.
Q4: Where is it used?
In GE Multilin UR-series relays for power system protection.
Q5: Can it operate alone?
No, it must be installed in a UR relay chassis.
Q6: What is the typical size?
About 152 × 178 × 38 mm.
Q7: What is the weight?
Roughly 0.6–1.5 kg depending on revision.
Q8: What is its main role in protection systems?
It provides accurate electrical measurements for protection algorithms like overcurrent, differential, and distance protection.
