Technical Specifications (GE Multilin UR Series)
| Parameter | Specification |
|---|---|
| Part Number | UR-8GH |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Series | UR (Universal Relay Series) |
| Product Type | CT/VT Ground Protection Module |
| Function | Provides current and voltage transformer input with sensitive ground fault protection |
| CT Inputs | Typically 3 phase CT + 1 ground CT (or 4 CT / 4 CT variants depending on configuration) |
| VT Inputs | Typically 4 VT inputs (system dependent configuration) |
| Frequency Range | 45–65 Hz |
| Isolation | ~2 kV AC RMS |
| Function Focus | Sensitive ground / earth fault detection |
| Communication | Internal UR backplane (relay CPU interface only) |
| Compatibility | GE Multilin UR-series relays |
| Mounting Type | Plug-in UR chassis module |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +95°C |
| Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | ≈ 263 × 58 × 28 mm |
| Weight | ≈ 0.9–1.2 kg |
FAQ
FAQ
Q1: What is UR 8GH used for?
It is used for CT/VT measurement and sensitive ground fault protection in UR relays.
Q2: Is it a relay or a module?
It is a plug-in measurement module, not a full relay.
Q3: What makes it different from other UR CT/VT modules?
It emphasizes enhanced ground fault sensitivity for better earth-fault detection.
Q4: Where is it used?
In GE Multilin UR protection systems for generators, feeders, and substations.
Q5: What signals does it handle?
It handles CT and VT secondary signals from instrument transformers.
Q6: What is its operating temperature?
Typically -40°C to +70°C.
Q7: What are its dimensions?
Approximately 263 × 58 × 28 mm.
Q8: What is its weight?
About 0.9–1.2 kg depending on revision.
