Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Multilin (GE Vernova) |
| Product Model | UR6BH |
| Product Series | Universal Relay (UR Series) |
| Product Type | Digital I/O Module |
| Function | Provides additional digital input and output channels for GE Multilin UR protection relays |
| Compatible Relays | GE Multilin UR family relays (such as T60, F60, C60, L90, etc.) |
| Module Type | Plug-in I/O expansion module |
| I/O Configuration | Digital input/output expansion |
| Number of Channels | 16 digital I/O channels |
| Signal Type | 24 VDC digital signals |
| Input Type | Dry contact / voltage sensing inputs |
| Output Type | Relay or transistor digital outputs (depending on configuration) |
| Rated Input Voltage | 24 VDC nominal |
| Operating Input Range | Typically 24–48 VDC |
| Output Voltage Range | 24 VDC control output |
| Output Current | Up to approximately 0.5 A per channel (configuration dependent) |
| Isolation Voltage | High-voltage isolation between field circuits and relay electronics |
| Communication Interface | Internal UR relay module bus |
| Configuration Software | EnerVista UR Setup |
| Hot Swap Capability | Supported in compatible UR relay configurations |
| Diagnostics | Module health monitoring and I/O status diagnostics |
| LED Indicators | Module status and I/O indication LEDs |
| Installation Location | UR relay rear expansion module slot |
| Compatible Platform | GE Multilin Universal Relay protection and control systems |
| Applications | Substation protection, feeder protection, transformer protection, generator protection, industrial automation |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 178 × 100 × 50 mm |
| Weight | Approx. 1.0 kg (2.2 lb) |
| Hardware Revision | H |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Multilin UR6BH used for?
The UR6BH is used to expand the digital input and output capability of GE Multilin Universal Relays, allowing connection to external switches, alarms, breakers, and control circuits.
Q2: Which GE relays are compatible with the UR6BH?
The UR6BH is designed for the GE Multilin Universal Relay platform and can be used with compatible UR-series relays such as feeder, transformer, motor, generator, and line protection relays.
Q3: How many I/O channels does the UR6BH provide?
The UR6BH provides 16 digital I/O channels for connection to external control and monitoring circuits.
Q4: What voltage level does the UR6BH support?
The module is designed for industrial 24 VDC digital signal applications, commonly used for protection relay control and monitoring circuits.
Q5: Can the UR6BH be used for breaker control applications?
Yes. The module can be configured for applications such as breaker trip/close control, status feedback, alarms, and interlocking logic when installed in a compatible UR relay system.
Q6: How is the UR6BH configured?
The module is configured through GE Multilin EnerVista UR Setup software, where users define I/O assignments, logic functions, and relay control schemes.
Q7: Does the UR6BH provide electrical isolation?
Yes. The module provides isolation between field-connected circuits and relay electronics to improve protection against electrical noise and transient conditions.
Q8: What should be checked before replacing a UR6BH module?
Before replacement, verify the UR relay model compatibility, existing I/O configuration, wiring connections, relay settings backup, module position, and EnerVista configuration to ensure correct operation.
